Diagnostics
112
7.5
Device Status
RM Web L2B
Release
5.3
05/2012
Figure 36: Device State dialog (for PowerMICE)
In the “Monitoring” field, you select the events you want to monitor.
The events which can be selected are:
Name Meaning
Power supply ... Monitor/ignore supply voltage(s).
ACA removal Monitor/ignore the removal of the ACA.
ACA not in sync Monitor/ignore non-matching of the configuration on the device and on
the ACA
a
.
Connection error Monitor/ignore the link status (Ok or inoperable) of at least one port.
The reporting of the link status can be masked for each port by the
management (see on page 28 “Port Configuration”). Link status is not
monitored in the state on delivery.
Table 28: Device Status
