Hirschmann OCTOPUS OS20 User Manual

Installation OCTOPUS OS20/OS24 Unmanaged
Release 07 07/2014
13
17 Operating voltage
(see on page 22)
A Rated voltage range DC
24 V ... 48 V
Observe the warning for railway standard
EN 50155!
(see on page 23)
Voltage range DC incl. maximum tolerances
9,6 V ... 60 V
Connection
type
M12
F Rated voltage range DC
24 V ... 48 V
Observe the warning for railway standard
EN 50155!
(see on page 24)
Voltage range DC incl. maximum tolerances
16,8 V ... 60 V
Connection
type
7/8" connectors, 5-pin
N Rated voltage range DC
72 V ... 110 V
Voltage range DC incl. maximum tolerances
50,4 V ... 138 V
Connection
type
7/8" connectors, 4-pin
18 Certifications E
 UL
 Railway (along track)
 Railway (train)
F
 UL
 Railway (along track)
 Railway (train)
 Germanischer Lloyd
 E1
19 Software variant U Unmanaged
20 Configuration H Hirschmann
21 Device model B IP54
Item Product
characteristic
Product code Value for the characteristic
Table 3: Device name
