12
Installation OCTOPUS OS20/OS24 Unmanaged
Release
07
07/2014
1.2 Description of the device variants
The table 2 informs you about the possible device variants.
The device name corresponds to the product code. The product code is
made up of variables with defined positions. The variable values stand for
specific product characteristics (see table 3).
Device name and product code Order number Characteristics
OS20-001000T5T5TAFUHB 942 025-001 24 V
OS20-001000T5T5TNEUHB 942 025-002 110 V
OS24-081000T5T5TFFUHB 942 025-003 24 V, PoE
OS24-081000T5T5TNEUHB 942 025-004 110 V, PoE
Table 2: Device types: product code, order number
Item Product
characteristic
Product code Value for the characteristic
1 ... 4 Product OS20 Octopus
device
with Fast Ethernet ports
without PoE ports
OS24 Octopus
device
with Fast Ethernet ports
with PoE+ ports
5 (hyphen) —
6 ... 7 Number:
Special ports
00 0 × PoE+ ports
08 8 × PoE+ ports
8 ... 9 Number:
100 Mbit/s ports
10 10 × 100 Mbit/s ports
(see on page 19)
10 ... 11 Number:
1000 Mbit/s ports
00 0 × 1000 Mbit/s ports
12 ... 13 uplink port T5 1 × 100 Mbit/s ports
Twisted pair
M12
14 ... 15 uplink port T5 1 × 100 Mbit/s ports
Twisted pair
M12
16 Temperature
range
T Extended −40 °F ... +158 °F (−40 °C ...
+70 °C)
Table 3: Device name
