36
Installation OCTOPUS OS3
Release
01
02/2019
EMC interference
emission
Standard applications
a
a. EN 61131-2, CE, FCC – applies to all devices
Railway applications
(trackside)
b
b. According to EN 50121-4.
Railway applications
(on vehicles)
c
c. According to EN 50155.
Radiated emission
EN 55032 Class A Class A Class A
FCC 47 CFR Part 15 Class A Class A Class A
EN 61000-6-4 Fulfilled Fulfilled Fulfilled
Conducted emission
EN 55032 AC and DC supply connections Class A Class A Class A
FCC 47 CFR Part 15 AC and DC supply connections Class A Class A Class A
EN 61000-6-4 AC and DC supply connections Fulfilled Fulfilled Fulfilled
EN 55032 Telecommunication connections Class A Class A Class A
EN 61000-6-4 Telecommunication connections Fulfilled Fulfilled Fulfilled
Table 12: EMC interference emission
EMC interference
immunity
Standard applications
a
Railway applications
(trackside)
b
Railway applications
(on vehicles)
c
Electrostatic discharge
EN 61000-4-2 Contact discharge ±4 kV ±6 kV ±6 kV
EN 61000-4-2 Air discharge ±8 kV ±8 kV ±8 kV
Electromagnetic field
EN 61000-4-3 80 MHz ... 3000 MHz max. 10 V/m max. 10 V/m max. 10 V/m
EN 61000-4-3 80 MHz ... 2700 MHz —
Fast transients (burst)
EN 61000-4-4 AC/DC supply connection ±2 kV ±4 kV
EN 61000-4-4 Data line ±4 kV ±4 kV
Table 13: EMC interference immunity
