Installation OCTOPUS OS3
Release
01
02/2019
37
Voltage surges - DC supply connection
EN 61000-4-5 line/ground ±2 kV ±2 kV
EN 61000-4-5 line/line ±1 kV ±1 kV
Voltage surges - AC supply connection
EN 61000-4-5 line/ground ±2 kV ±2 kV
EN 61000-4-5 line/line ±1 kV ±1 kV
Voltage surges - data line
EN 61000-4-5 line/ground ±1 kV ±2 kV
Conducted disturbances
EN 61000-4-6 150 kHz ... 80 MHz 10 V 10 V
Damped oscillation - AC/DC supply connection
EN 61000-4-12 line/ground — —
EN 61000-4-12 line/line — —
Damped oscillation – data line
EN 61000-4-12 line/ground — — —
EN 61000-4-12 line/line — — —
Pulse magnetic field
EN 61000-4-9 — — —
a. EN 61131-2, CE, FCC – applies to all devices
b. According to EN 50121-4.
c. According to EN 50155.
EMC interference
immunity
Standard applications
a
Railway applications
(trackside)
b
Railway applications
(on vehicles)
c
Table 13: EMC interference immunity
