Hirschmann RS20 series User Manual

Installation RS20/22/30/32/40
Release 05 12/2015
69
Figure 25: Dimensions of device variants RS22.../RS32... with 16 to 26 ports with
operating temperature characteristic value S, T and E
Figure 26: Dimensions of RPS90/48V LV and RPS90/48V HV PoE power units
120
115
137
4.73
9
0.36
4.53
12
0.47
5.39
60
115
7,05
137
4.53 0.28
5.39
9
0.36
2.36

Hirschmann RS20 series Specifications

General

Port Count	Up to 24 ports
Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-forward
Port Type and Speed	10/100BASE-TX, 100BASE-FX
Power Supply	24 V DC or 110-230 V AC
Certifications	CE, UL, cUL, DNV, GL, ABS, IECEx, ATEX
Management	Web, SNMP, CLI
Redundancy	MRP, RSTP
Dimensions	Varies depending on model
Weight	500 g
