70
Installation RS20/22/30/32/40
Release
05
12/2015
EMC and immunity
EMC compliance – IEC/EN 61000-6-2:2005 EMI TYPE tests,
test acc. to:
A
a)
B
a)
H
a)
IEC/EN 61000-4-2 Electrostatic discharge
Contact discharge
Air discharge
4kV
8 kV
8 kV
15 kV
8 kV
15 kV
IEC/EN 61000-4-3 Electromagnetic field
80 MHz ... 3000 MHz 10 V/m 20 V/m 20 V/m
IEC/EN 61000-4-4 Fast transients (burst)
Power line
Data line
2kV
1 kV
4kV
4kV
4kV
4kV
IEC/EN 61000-4-5 Voltage surges
Power line, line / line
Power line, line / ground
Data line
0.5 kV
1 kV
1 kV
1 kV
2kV
4kV
1 kV
2kV
4kV
IEC/EN 61000-4-6 Conducted disturbances
10 kHz - 150 kHz
150 kHz ... 80 MHz
3 V
10 V
3 V
10 V
3 V
10 V
EN 61000-4-9 Pulse magnetic fields — 300 A/m 300 A/m
EMC interference emission A
a)
B
a)
H
a)
EN 55022 Class A Yes Yes Yes
FCC 47 CFR Part
15
Class A Yes Yes Yes
German Lloyd Classification + Construction Guidelines VI-
7-3 Part 1 Ed.2001
—YesYes
Stability A
a
a. Product code A: Approval = CE, UL
Product code B: Approval = CE, UL, GL, railway (along track), Sub Station, ATEX/IECEx
Produktcode H: Zulassung = CE, UL, GL, Bahn (along track), Sub Station
(See “Combination options of the device variants RS20/RS30/RS22/RS32” on page 23.
See “Combination options for the RS40 device variants” on page 26.)
B
a)
H
a)
Vibration IEC 60068-2-6 Test FC test level according
to IEC 61131-2
Yes Yes Yes
Germanischer Lloyd Guidelines for the
Performance of Type Tests Part 1
—YesYes
IEC 870-2-2 table 3 normal installation
according to EN 61850-3
—YesYes
Shock IEC 60068-2-27 Test Ea test level according
to IEC 61131-2
Yes Yes Yes
IEC 870-2-2 table 3 normal installation
according to EN 61850-3
—YesYes
