Hirschmann RS20 series User Manual

Installation RS20/22/30/32/40
Release 05 12/2015
73
 Power consumption/power output
Device name Device model Maximum
power
consumption
Power output
2 uplink ports:
RS20-0400... 2xTX port 5.3 W 18.1 Btu (IT)/h
RS20-0400... 1xFX port, 1xTX port 6.5 W 22.2 Btu (IT)/h
RS20-0400... 2xFX port 7.7 W 26.3 Btu (IT)/h
RS20-0800... RS22-0800... 2xTX port 5.3 W 18.1 Btu (IT)/h
RS20-0800... RS22-0800... 1xFX port, 1xTX port 6.5 W 22.2 Btu (IT)/h
RS20-0800... RS22-0800... 2xFX port 7.7 W 26.3 Btu (IT)/h
RS20-1600... RS22-1600... 2xTX port 9.4 W 32.1 Btu (IT)/h
RS20-1600... RS22-1600... 1xFX port, 1xTX port 10.6 W 36.2 Btu (IT)/h
RS20-1600... RS22-1600... 2xFX port 11.8 W 40.3 Btu (IT)/h
RS20-2400-... RS22-2400-... 2xTX port 12.1 W 41.3 Btu (IT)/h
RS20-2400-... RS22-2400-... 1xFX port, 1xTX port 13.3 W 45.4 Btu (IT)/h
RS20-2400-... RS22-2400-... 2xFX port 14.5 W 52.9 Btu (IT)/h
RS30-0802-... RS32-0802-... 2xTX port 8.9 W 30.4 Btu (IT)/h
RS30-0802-... RS32-0802-... 1xFX port, 1xTX port 8.6 W 29.4 Btu (IT)/h
RS30-0802-... RS32-0802-... 2xFX port 8.3 W 28.4 Btu (IT)/h
RS30-1602-... RS32-1602-... 2xTX port 13.0 W 44.4 Btu (IT)/h
RS30-1602-... RS32-1602-... 1xFX port, 1xTX port 12.7 W 43.4 Btu (IT)/h
RS30-1602-... RS32-1602-... 2xFX port 12.4 W 42.4 Btu (IT)/h
RS30-2402-... RS32-2402-... 2xTX port 15.7 W 53.6 Btu (IT)/h
RS30-2402-... RS32-2402-... 1xFX port, 1xTX port 15.4 W 52.6 Btu (IT)/h
RS30-2402-... RS32-2402-... 2xFX port 15.1 W 51.6 Btu (IT)/h
3 uplink ports:
RS20-0900-... RS22-0900-... 3xFX port 9.6 W 32.8 Btu (IT)/h
RS20-1700-... RS22-1700-... 3xFX port 13.7 W 46.7 Btu (IT)/h
RS20-2500-... RS22-2500-... 3xFX port 16.4 W 56.0 Btu (IT)/h
4 uplink ports:
RS30-0802-... RS32-0802-... 4xFX port 12.7 W 43.3 Btu (IT)/h
RS30-1602-... RS32-1602-... 4xFX port 16.8 W 57.3 Btu (IT)/h
RS30-2402-... RS32-2402-... 4xFX port 19.5 W 66.5 Btu (IT)/h
RS40-... 4xFX port 20.0 W 68.2 Btu (IT)/h
Table 20: Power consumption/power output RS20/RS30/RS40 and RS22/RS32
without PDs (powered devices)
Device name Device model Maximum
power
consumption
Power output
2 uplink ports:
RS22-0800... 2xTX port 70.9 W 31.8 Btu (IT)/h
RS22-0800... 1xFX port, 1xTX port 72.1 W 35.9 Btu (IT)/h
Table 21: Power consumption/power output RS22/RS32 with 4 x Class0 PD
(powered device)

Hirschmann RS20 series Specifications

General

Port Count	Up to 24 ports
Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-forward
Port Type and Speed	10/100BASE-TX, 100BASE-FX
Power Supply	24 V DC or 110-230 V AC
Certifications	CE, UL, cUL, DNV, GL, ABS, IECEx, ATEX
Management	Web, SNMP, CLI
Redundancy	MRP, RSTP
Dimensions	Varies depending on model
Weight	500 g
