74
Installation RS20/22/30/32/40
Release
05
12/2015
Scope of delivery
RS22-0800... 2xFX port 73.3 W 40.0 Btu (IT)/h
RS22-1600... 2xTX port 75.0 W 45.8 Btu (IT)/h
RS22-1600... 1xFX port, 1xTX port 76.2 W 49.9 Btu (IT)/h
RS22-1600... 2xFX port 77.4 W 54.0 Btu (IT)/h
RS22-2400-... 2xTX port 77.7 W 55.0 Btu (IT)/h
RS22-2400-... 1xFX port, 1xTX port 78.9 W 59.1 Btu (IT)/h
RS22-2400-... 2xFX port 80.1 W 66.6 Btu (IT)/h
RS32-0802-... 2xTX port 74.5 W 44.1 Btu (IT)/h
RS32-0802-... 1xFX port, 1xTX port 74.2 W 43.1 Btu (IT)/h
RS32-0802-... 2xFX port 73.9 W 42.1 Btu (IT)/h
RS32-1602-... 2xTX port 78.6 W 58.1 Btu (IT)/h
RS32-1602-... 1xFX port, 1xTX port 78.3 W 57.1 Btu (IT)/h
RS32-1602-... 2xFX port 78.0 W 56.1 Btu (IT)/h
RS32-2402-... 2xTX port 81.3 W 67.3 Btu (IT)/h
RS32-2402-... 1xFX port, 1xTX port 81.0 W 66.3 Btu (IT)/h
RS32-2402-... 2xFX port 80.7 W 65.3 Btu (IT)/h
3 uplink ports:
RS22-0900-... 3xFX port 75.2 W 46.5 Btu (IT)/h
RS22-1700-... 3xFX port 79.3 W 60.4 Btu (IT)/h
RS22-2500-... 3xFX port 82.0 W 69.7 Btu (IT)/h
4 uplink ports:
RS32-0802-... 4xFX port 78.3 W 57.0 Btu (IT)/h
RS32-1602-... 4xFX port 82.4 W 71.0 Btu (IT)/h
RS32-2402-... 4xFX port 85.1 W 80.2 Btu (IT)/h
Device Scope of delivery
RS20-..., RS30-..., RS40-...,
RS22-... or RS32-...
Device
Terminal block for supply voltage and signal contact
Installation user manual and CD/DVD
RS22-16..., RS22-17...,
RS22-24..., RS22-25...
Additionally: ferrite with key
Device name Device model Maximum
power
consumption
Power output
Table 21: Power consumption/power output RS22/RS32 with 4 x Class0 PD
(powered device)
