Redundancy
90
6.1
Ring Redundancy
RM Web L2B
Release
5.3
05/2012
Note: Configure all the devices of the MRP-Ring individually. Before you
connect the redundant line, you must have completed the configuration of all
the devices of the MRP-Ring. You thus avoid loops during the configuration
phase.
Parameter Meaning
Ring port X.X
operation
Display in “Operation” field:
forwarding: This port is switched on and has a link.
blocked: This port is blocked and has a link.
disabled: This port is switched off.
not connected: This port has no link.
Ring
Manager
Configuration
Deactivate the advanced mode if a device in the ring does not support the
advanced mode for fast switching times. Otherwise you activate the advanced
mode.
Note: All Hirschmann devices that support the MRP-Ring also support the
advanced mode.
Ring
Manager
Mode
If there is exactly one device, you switch the Ring Manager function on at the
ends of the line.
Operation When you have configured all the parameters for the MRP-Ring, you switch the
operation on with this setting. When you have configured all the devices in the
MRP-Ring, you close the redundant line.
Ring
Recovery
For the device for which you have activated the ring manager, select the value
200 ms if the stability of the ring meets the requirements for your network.
Otherwise select 500 ms.
Note: Settings in the “Ring Recovery” frame are only effective for devices that
are ring managers.
Information If the device is a ring manager: The displays in this frame mean:
“Redundancy working”: When a component of the ring is down, the redundant
line takes over its function.
“Configuration failure”: You have configured the function incorrectly, or there is
no ring port connection.
Table 24: MRP-Ring configuration
