Installation RSPE 30/32/35/37
Release 12 10/2015
37
2.4 Installing and grounding the device
2.4.1 Installing the device onto the DIN rail
Verify that the device maintains the minimum clearing in order to meet the
climatic conditions:
 Top and bottom device side: 3.94 in (10 cm)
 Left and right device side: 0.79 in (2 cm)
Undercutting the minimum clearing reduces the specified maximum
operating temperature (see on page 53 “General technical data”).
To mount the device onto a horizontally mounted 35 mm DIN rail according
to DIN EN 60715, proceed as follows:
 Slide the upper snap-in guide of the device into the DIN rail.
 Press the media module downwards onto the clip-in bar.
 Snap in the device.
WARNING
FIRE HAZARD
Install the device in a fire enclosure according to EN 60950-1.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
WARNING
ELECTRIC SHOCK
Install this device solely in a switch cabinet or in an operating site with
restricted access, to which maintenance staff have exclusive access.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
