Hirschmann RSPE 32 User Manual

54
Installation RSPE 30/32/35/37
Release 12 10/2015
Supply voltage
with the
characteristic
value PP
See “Requirements for connecting electrical wires” on page 6.
Nominal voltage DC When using PoE: 48 V
When using PoE+: 54 V
Without using PoE or PoE+:
24 V ... 48
a
Voltage range DC incl.
maximum tolerances
When using PoE: 47 V... 57 V
Rated current DC RSPE30/32 3.1 A ... 3.5 A
RSPE35/37
When using PoE+: 53 V... 57 V
Without using PoE or PoE+:
19 V ... 60 V
a
Max. PoE power In total: 124 W
Per media module: 62 W
Connection type 2-pin terminal block
Power loss buffer > 10 ms at 20.4 V DC
Overload current protection at
input
Non-replaceable fuse
Back-up fuse Nominal rating: 6.3 A
Characteristic: slow blow
Peak inrush current < 5 A
Climatic
conditions
during
operation
Minimum clearance around the
device
Top and bottom device side: 3.94 in (10 cm)
Left and right device side: 0.79 in (2 cm)
Derating
b
:
3 K at the following clearance:
Top and bottom device side: 0.79 in (2 cm)
Left and right device side: 0 in
Ambient air temperature
c
Devices with operating temperature
characteristic value S (standard):
+32 °F ... +140 °F (0 °C ... +60 °C)
d
Devices with operating temperature
characteristic value E and T (extended):
 RSPE 32, RSPE 37:
−40 °F ... +158 °F (−40 °C ... +70 °C )
e,f
−40 °F ... +185 °F (−40 °C ... +85 °C) for 16
hours (tested in accordance with
IEC 60068-2-2)
d,g
 RSPE 30, RSPE 35:
−40 °F ... +158 °F (−40 °C ... +70 °C )
d
−40 °F ... +185 °F (−40 °C ... +85 °C) for
16 hours (tested in accordance with
IEC 60068-2-2)
d
Maximum inner temperature of
device (guideline)
Devices with operating temperature
characteristic value S (standard):
190 °F (88 °C)
Devices with operating temperature
characteristic value E and T (extended):
208 °F (98 °C)
Humidity 5 % ... 95 % (non-condensing)
Air pressure minimum 700 hPa (+9842 ft; +3000 m)
maximum 1060 hPa (−1312 ft; −400 m)
