Hisense 32A5100F - TV Rear

5
TV Rear
TV Rear
HDMI 2 HDMI 1(ARC)
USB
DC 5V 0.5A(MAX
)
DIGITAL
AUDIO OUT
ANT 1
DVB-T/T2/C
COMMON INTERFACE(CARD FACE FRONT)
AV IN HEADPHONE
ANT 2
DVB-S/S2
13/18V 400mA
Power cord
32"
NOTES
ANT2 Jack supports power supply for satellite antenna (13/18V, 400mA
max.)
Check the jacks for position and type before making any connections.
Loose connections can result in image or color problems. Make sure
that all connections are tight and secure.
Not all A/V devices have the ability to connect to a TV, please refer to
the user’s manual of your A/V device for compatibility and connections
procedure.
Before connecting external equipment, remove the mains plug from the
wall socket. Otherwise, it may cause electric shock.
