Hisense APC09 User Manual

17
Rain cover--Horizontal Installation
NOTE: For casement window installation, the window slider kit
may be installed vertically with the window slider kit opening
at the bottom.
3. Open the window.
4. Measure the window opening.
If the window opening is too narrow for the window slider kit,
remove the inner slider section from the window slider kit.
■
6. Inset ½” screw (provide 2) into the hole in the inner slider
section that is closest to the end of the outer slider section of
A. ½”screw (provide 2)
B. Inner slider section
C. Outer slider section
7. Close the window onto the window slider kit to secure.
A. To air conditioner
B. Outdoors
C. Rain cover
portable
D. Window slider kit
E. Window exhaust adapter
F. Flexible exhaust hose
A
B
C
D
A B
C
E
F
A. Window exhaust adapter
B. Rain cover
C. Outlet grille
D. Bolts inserted into unused
holes in Window slider kit
A. Inner slider section
B. Outer slider section
Using a saw, cut the inner slider section to fit the window
opening.
Slide the inner slider section into the outer slider section of
the window slider kit.
■
■
5. Place the window slider kit into the window, extending it to fit
the width of the window. Be sure the rain cover is on the
outside of the window.
A
B
A
B
C
D

Hisense APC09 Specifications

General

Type	Monobloc mobile air conditioner
Timer type	Digital
Noise level	64 dB
Airflow (high speed)	380 m³/h
Refrigerating medium	R290
Dehumidifier function	Yes
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying
Refrigerating medium weight	260 g
Suitable for room area up to	36 m²
Cooling capacity in watts (max)	- W
Cooling capacity in watts (nominal)	2600 W
Cooling energy efficiency (EER, W/W)	2.6
Heating energy efficiency (COP, W/W)	-
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	No
Hourly energy consumption (cooling)	- kWh
Product color	White

Weight and Dimensions

Depth	325 mm
Width	430 mm
Height	690 mm
Weight	30000 g
Package depth	380 mm
Package width	480 mm
Package height	880 mm
Package weight	34000 g
