Hisense APH12 User Manual

18
Complete Installation
1. Place the window-lock bracket on top of the lower window and
against the upper window sash.
2. Use 1/8” drill bit to drill a starter hole through the hole in the
bracket.
3. Attach the window-lock bracket to the window sash with wood
screw(provide 4) to secure the window in place.
A. Upper window sash
B. Window-lock bracket
4. Insert the foam seal behind the top of the lower window sash
and against the glass of the upper window.
A. Top of lower window sash
B. Foam seal
A
B
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
WARNING
fire, or electrical shock.
5. Plug into a grounded 3 prong outlet.
A
B

Hisense APH12 Specifications

General

Type	Split system
Multi-split	No
Timer type	Digital
Noise level	64 dB
Number of speeds	3
Remotely operated	Yes
Airflow (high speed)	380 m³/h
Refrigerating medium	R290
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.3 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Fan, Heating
Refrigerating medium weight	300 g
Suitable for room area up to	36 m²
Cooling capacity in watts (max)	- W
Cooling capacity in watts (nominal)	3500 W
Heating capacity in watts (nominal)	3000 W
Cooling energy efficiency (EER, W/W)	2.6
Heating energy efficiency (COP, W/W)	2.8
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	A+
Hourly energy consumption (cooling)	- kWh
Display type	LED
Product color	White

Weight and Dimensions

Depth	382 mm
Width	442 mm
Height	750 mm
Weight	35000 g
Package weight	39500 g
