L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm)
590 520 55 51 560 490 50 mini
Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air
inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As
shown below
Note: The safety distance between the hotplate and the cupboard above the
hotplate should be at least 760mm.
15
