Hisense HS3100 User Manual

EN
10
6.4 Use the OPTICAL Socket
- Use the OPTICAL cable to connect the TV’s
OPTICAL OUT socket and the OPTICAL
socket on the soundbar.
56:/)'2
.*3/'8)
56:/)'2
.*3/
'8)
.KGJVNUTK
BA
Tip:
The Soundbar may not be able to decode all
digital audio formats from the input source. In this
case, the Soundbar will mute. This is NOT a defect.
Ensure that the audio setting of the input source
(e.g. TV, game console, DVD player, etc.) is set to
PCM or Dolby Digital (Refer to the user manual
of the input source device for its audio setting
details) with HDMI ARC / OPTICAL input.
6.5 Use the AUX Socket
A. Use a 3.5mm to 3.5mm audio cable to connect
the TV’s or external audio device headphone
socket to the AUX socket on the soundbar.
56:/)'2
.*3/'8)
56:/)'2
.*3/
'8)
.KGJVNUTK
BA
B. Use a RCA to 3.5mm audio cable to connect
the TV’s audio output sockets to the AUX
socket on the soundbar.
6.6 Connect Power
Risk of product damage!
• Risk of product damage! Ensure that the power
supply voltage corresponds to the voltage printed
on the back or the underside of the soundbar.
• Before connecting the AC power cord, ensure
you have completed all other connections.
• Soundbar
Connect the mains cable to the AC~ socket of
the soundbar and then into a mains socket.
• Subwoofer
Connect the mains cable to the AC~ socket
of the subwoofer and then into a mains
socket.
* Power cord quantity and plug very by regions.
7. Pa ir u p with the Subwoofer
7.1 Automatic pairing
The subwoofer and soundbar will automatically
pair when both units are plugged into the mains
sockets and turned on. No cable is needed for
connecting the two units.
• Determine the status based on the wireless
subwoofer indicator.
LED State Status
Fast blink
Subwoofer in pairing mode
Constant on
Connected / Pairing successful
Slow blink
Connection / Pairing Failed
NOTE:
- Do not press the PAIR button on the rear of
the subwoofer, except for manual pairing.
- If the automatic pairing fails, pair the
subwoofer with the soundbar manually.
11
7.2 Manual pairing
1. Ensure that all the cables are well connected
and the soundbar is in Standby mode.
2. Press and hold the PAIR button on the rear
of the subwoofer for a few seconds. The
subwoofer will enter the pairing mode and
the Pair Indicator will blink quickly.
3. Press the
button on the soundbar or on the
remote control to switch the soundbar on.
4. Press and hold the
button on the Soundbar
or on the remote control for a few seconds.
5. After the wireless connection succeeded, the
Pair Indicator will light up.
6. If the Pair indicator blinks, the wireless
connection has failed. Unplug the cable of
the subwoofer and then reconnect the main
cable after 4 minutes. Repeat step 1 ~ 4.
NOTE:
• If the wireless connection fails again, check
if there is conict or strong interference (for
example, interference from an electronic
device) around your location. Remove these
conflicts or strong interferences and repeat
the above procedures.
• The subwoofer should be within 6m (19.7 feet)
of the soundbar in an open area.
• If the soundbar is not connected with the
subwoofer and it is in On mode, the POWER
Indicator will flash. Follow step 1 ~ 4 above
to pair the subwoofer to the soundbar.
8. Basic Operation
8.1 Standby/ON
It will automatically turn on when the power cord
is connected.
• Press the
button to switch the soundbar
STANDBY mode.
• Disconnect the mains plug from the mains
socket if you want to switch the soundbar
OFF completely.
8.2 Auto-Standby / Auto-Wake Feature
[Auto-Standby] Your soundbar has been
programmed to enter STANDBY mode
automatically when no audio is detected for 15
minutes. For example, this would happen when
pausing playback, or should the soundbar be left
on accidentally.
[Auto-Wake] If a TV or an external device is
connected (AUX / OPTICAL / HDMI ARC mode), the
unit will switch on automatically when the TV or
the external device is switched on.
To disable this feature, please follow the steps
below:
1. During ON mode, press and hold the
button for 3 seconds to open the menu.
- The unit’s display will scroll “MENU”.
2. Press the
button 6 times in succession:
the display shows: Auto Wake [ON / OFF].
or Press the
button 7 times in succession:
the display shows: Auto Standby [ON / OFF].
3. Select the content with VOL+ /

buttons on
the remote control, and then press the
button to conrm your selection and exit the
settings.
• Repeating these steps will toggle the feature
"ON" and "OFF".
