- 15 -
LCD TV Service Manual
Hisense Confidential
4.2 Main BD
Location No.
SPECIFICATION
Description
CON10 PH2.54X8.5 2X30P 90\ROH connect Main BD and Terminal BD
CON8 FF-HX19-10\ROH LVDS
CON10
CON8
