Hisense LCD40V57CA - Exploded View and Parts List; Exploded Bill of Materials (BOM)

- 44 -
LCD TV Service Manual
Hisense Confidential
8. Explode View and explode BOM List
Explode BOM List：
LCD40V57CA
No. Part Name Num. Code No. Remark
1 lamp bar unit 1 B-700-500
2 LCD PANEL 1 LTA400AA04
3 IR Board Unit 1 RSAG2.908.102
4 Key Board Unit 1 RSAG2.908.108
5 Main Board Unit 1 RSAG2.908.1101-15
6 Power Board Unit 1 RSAG2.908.982-4
7 Bracket Unit 1 RSAG6.150.349
8 Terminal bracket 1 RSAG8.041.182
9 front cover 1 RSAG8.074.467
10 Back cover 1 RSAG8.074.468
11 bracket 1 RSAG8.078.480
12 bracket 1 RSAG8.078.481
13 Terminal bracket 1 RSAG8.081.312
14 key 1 RSAG8.335.067
15 baffle 1 RSAG8.634.047
16 Lens led 1 RSAG8.640.056
17 ornament 1 RSAG8.647.247
18 base unit 1 WG6.121.052
19 speaker 2 YDT415E-10W8R-F
20 Screw 23 SJ2836-87 M3X8
21 Screw 2 GB/T 818-2000 M4X8
22 Screw 37 SJ2824-87 ST4X14F
23 Screw 4 SJ2825-87 ST3X12C
24 Screw 7 SJ2832-87 ST3X10
25 Screw 4 SJ2838-87 ST4X16C.II
26 terminal board unit 1 RSAG2.908.1153-3
27 Terminal bracket 1 RSAG8.041.182
28 scutcheon 1 RSAG8.804.3233
29 bracket 15 RSAG8.078.485
30 cover board 1 RSAG8.634.057
31 power tie 1 RSAG8.667.014
32 scutcheon 1 RSAG8.804.317
33 Screw 4 GB/T 818-2000 M6X16
