Hisense MSD6586 - Board 7918 Terminals & Socket Description

- 14 -
Board 7918 terminals & socket description
NO. Position Description
1 U8 RF terminal
2 XS10 PCMCIA
3 XS1 Service
4 XS6 HDMI1(4K@ 60Hz) ARC
5 XS7 HDMI2(4K@ 60Hz)
6 XS2 SPDIF
7 XS11 USB1
8 XS15 HDMI3(4K@ 60Hz)
9 XS4 LAN
10 XS3 AV input
11 XP15 IR/KEY/WIFI/LED
12 XP9 Speaker
13 XP13 ISP output-L
13 XP14 ISP output-R
14 XP1 Main power connector input
15 Round N33 PMU-IC TCON part on the board
16 XS12 USB2
