Hisense MSD6586 - TV Boards Part List

- 16 -
2.2 TV boards part list
Main board Boards function difference
Main chassis type
For Series
RSAG7.820.7000\ROH
1. Lateral terminal and vertical terminal.
2. TCON part not on the board.
3. Support HEVC 60Hz decoding, support HDMI
2.0/HDCP 2.2.
4. Support 8 lane VBO output, the resolution support
up to 4K*2K/60Hz.
MSD6586PGE  suitable for
HE50N3050UWTS.
RSAG7.820.7918\ROH
1. Lateral terminals.
2.TCON part on the board.
3. Support HEVC 60Hz decoding, support HDMI
2.0/HDCP 2.2.
4. The resolution support up to 4K*2K/60Hz.
5 Unit 7918 board use XP13 &XP14 to transfer
signal to Panel.
MSD6586PGET suitable for
HEXXA6100UWTS
RSAG7.820.7921\ROH
1. Lateral terminal and vertical terminal.
2. TCON part not on the board.
3. Support HEVC 60Hz decoding, support HDMI
2.0/HDCP 2.2.
4. Support 8 lane vbyone output, the resolution
support up to 4K*2K/60Hz.
5、Unit 7921 board use XP3 to transfer vbyone
signal to Panel
MSD6586PGE  suitable for
HE65A6100UWTS
