2.2 Wiring diagram( example for 55E70LEVS):
XP2： Power for main board jacket
Main board terminal Power board terminal
Pin definition Pin definition
1
IR_IN
1
IR_IN
2
GND
2
GND
3
LED
3
LED-1
4
3.3V_SENSOR2
4
3.3V
5
3.3Vstb
5
3.3Vstb
6
SCL
6
SCLR
7
SDA
7
SDA
8
KEY1
8
KEY0
9
GND
9
GND
