13
-
10
LED_OFF
10
LED_2
11
GND
XP12：68pin P2P jacket
Main board terminal jacket definition
Panel terminal jacket definition
Pin
Definition
illustration Pin
definition
1 CTRL7 Control pin 68 NC
2 CTRL6 Control pin 67 NC
3 CTRL5 Control pin 66 NC
4 CTRL4 Control pin 65 TEND
5 CTRL3 Control pin 64 VCE
6 CTRL2 Control pin 63 LC
7 CTRL1 Control pin 62 YDIO1
8 GND Ground 61 GND
9 X0B_0P 60 P2P1P
10 X0B_0N 59 P2P1N
11 GND Ground 58 GND
12 X0B_1P 57 P2P2P
13 X0B_1N 56 P2P2N
14 GND Ground 55 GND
15 X0B_2P 54 P2P3P
16 X0B_2N 53 P2P3N
17 GND Ground 52 GND
18 X0B_3P 51 P2P4P
19 X0B_3N 50 P2P4N
20 GND Ground 49 GND
21 X0B_4P 48 P2P5P
22 X0B_4N 47 P2P5N
23 GND Ground 46 GND
24 X0B_5P 45 P2P6P
25 X0B_5N 44 P2P6N
26 GND Ground 43 GND
27 X0B_6P 42 P2P7P
28 X0B_6N 41 P2P7N
29 GND Ground 40 GND
30 X0B_7P 39 P2P8P
31 X0B_7N 38 P2P8N
32 GND Ground 37 GND
