33 X0B_8P 36 P2P9P
34 X0B_8N 35 P2P9N
35 GND Ground 34 GND
36 X0B_9P 33 P2P10P
37 X0B_9N 32 P2P10N
38 GND Ground 31 GND
39 X0B_10P 30 P2P11P
40 X0B_10N 29 P2P11N
41 GND Ground 28 GND
42 X0B_11P 27 P2P12P
43 X0B_11N 26 P2P12N
44 GND Ground 25 GND
45 P2P_LOCK 24 P2P_LOCK
46 GND Ground 23 GND
47 MSPI1_MIS
O
LDC_DATA_I 22 NC
48 MSPI1_MO
SI
LDC_DATA_O 21 NC
49 MSPI1_SCK LDC_CLK 20 NC
50 MSPI1_SCZ DENURA_CS 19 NC
51 GND Ground 18 GND
52 T_nWR Write protect 17 nWR
53 T_SCL I2C CLK 16 SCL
54 T_SDA I2C DATA 15 SDA
55 GND Ground 14 GND
56 GND Ground 13 GND
57 GND Ground 12 GND
58 GND Ground 11 GND
59 GND Ground 10 GND
60 NC 9 NC
61 12V_PANEL Power Supply Input
Voltage
8 VCC_PANEL
62 12V_PANEL Power Supply Input
Voltage
7 VCC_PANEL
63 12V_PANEL Power Supply Input
Voltage
6 VCC_PANEL
64 12V_PANEL Power Supply Input
Voltage
5 VCC_PANEL
65 12V_PANEL Power Supply Input
Voltage
4 VCC_PANEL
66 12V_PANEL Power Supply Input
Voltage
3 VCC_PANEL
