LCD TV Service Manual
Hisense Confidential
Input by P9, pass the below circuit diagram and enter U34 for disposal.
PC signal enter through XS11, input U34 by passing the below similar disposal, check the diagram for detail.
The Audio signal of HDMI and USB directly input U34 for disposal.
AV output send out by the No.11 feet of U34, through the below diagram, finally come out by P4.
The input Video signal send out the LVDS signal after the U34 managed, the LVDS signal will pass CN9 and
go to LCD panel display.
