Hisense WFUA7012 User Manual

9. TROUBLESHOOTING
30
9.3 TROUBLESHOOTING
WITH ERROR
WATER INLET ERROR
Is displayed?
Yes
Is filter inlet valve clogged
with foreign material?
Clean or
replace the
filter.
Yes
No
Is the connector connected
to inlet valve disconnected
or disassembled?
Yes
No
Reconnect
or repair the
connector.
Is resistance between each
terminal of inlet valve 3.79-
3.85 kΩ？（Refer to 10-5
inlet valve）
Replace the
inlet valve
No
Yes
Is the voltage of the inlet
valve connector 220-240
V?( while the power is on)
Replace the
inlet valve
Yes
No
Replace the PCB
Is the connector connected
to PCB disconnected or dis-
assembled?
Reconnect
or repair the
connector.
Yes
No
Is Electrical connection
correct? (Refer to 10-5)
Replace the
main harness
Yes
No
Is the water level frequency
below 24.6 kHz? (Refer to 8-
2)
Replace the
FWL sensor
Yes
No
[Note] Environmental safety check list
1) No water tap leakage
2) No water tap freeze
3) No entanglement of water supply hose
4) No water shortage
5) No shrinkage on water supply hose due to a
possible misuse of hot and cold water
6) No water supply hose leakage

Hisense WFUA7012 Specifications

General

Door hinge	Left
Control type	Buttons
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drum capacity	7 kg
Spin-drying class	B
Maximum spin speed	1200 RPM
Noise level (spin)	72 dB
Noise level (wash)	57 dB
Number of washing programs	15
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption washing per cycle	- kWh
Annual water consumption washing	8990 L
Annual energy consumption washing	174 kWh
Package depth	645 mm
Package width	650 mm
Package height	885 mm
Package weight	74000 g

Weight and Dimensions

Depth	600 mm
Width	595 mm
Height	850 mm
Weight	72000 g
