Hisense WFUA7012 User Manual

10. COMPONENT TESTING INFORMATION
44
10.6 HEATER
Wiring
diagram
Function
The wash heater is designed to raise the wash water to the desired temperature
selection during certain wash cycles.
Test points
and result
Test points Result Remarks
1-2 25.5±5%Ω
Circuit in the PCB / Wiring Diagram
1
2

Hisense WFUA7012 Specifications

General

Door hinge	Left
Control type	Buttons
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drum capacity	7 kg
Spin-drying class	B
Maximum spin speed	1200 RPM
Noise level (spin)	72 dB
Noise level (wash)	57 dB
Number of washing programs	15
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption washing per cycle	- kWh
Annual water consumption washing	8990 L
Annual energy consumption washing	174 kWh
Package depth	645 mm
Package width	650 mm
Package height	885 mm
Package weight	74000 g

Weight and Dimensions

Depth	600 mm
Width	595 mm
Height	850 mm
Weight	72000 g
