32PD3000 / 42PD3000
10
1st 2nd 3rd 4th 5th
32"
values
hex
37"
values
hex
42"
values
hex
functions Device
APC 00 00 00
APC switch 0;High APC,
1;Normal
PDP 10 D7
MI0> M01> F01(4:3) 01 01 01
wide mode selected by 16:9
key (0;on, 1;off)
4:3
F02(16:9) 00 00 00
wide mode selected by 16:9
key (0;on, 1;off)
WIDE
SCREEN
F03(C16:9L) 00 00 00
wide mode selected by 16:9
key (0;on, 1;off)
LETTERBOX
*** MAX 8 items on one page.
F04(T16:9L) 01 01 01
wide mode selected by 16:9
key (0;on, 1;off)
T16:9L
F05(14:9) 01 01 01
wide mode selected by 16:9
key (0;on, 1;off)
14:9
M02> F06(C14:9L) 00 00 00
wide mode selected by 16:9
key (0;on, 1;off)
C14:9L
F07(T14:9L) 01 01 01
wide mode selected by 16:9
key (0;on, 1;off)
T14:9L
F08(PAN) 01 01 01
wide mode selected by 16:9
key (0;on, 1;off)
PANORAMIC
F09(14:9LS) 00 00 00
wide mode selected by 16:9
key (0;on, 1;off)
14:9 ZOOM
PCA 02 02 02
PC wide mode 0;NORMAL,
1;REAL, 2;FULL
FC4 3 D17:D16
*** LTI ***
M03> HE1 02 02 02
Horizontal enhancer
DYNAMIC
FC4 2 D20:D19
picture mode
HE2 03 03 03
Horizontal enhancer
DYNAMIC-VIDEO
FC4 2 D20:D19
HE3 00 00 00
Horizontal enhancer
NATURAL
FC4 2 D20:D19
HE4 00 00 00
Horizontal enhancer
NATURAL-VIDEO
FC4 2 D20:D19
HE5 01 01 01
Horizontal enhancer CINEMA FC4 2 D20:D19
HE6 02 02 02
Horizontal enhancer CINEMA-
VIDEO
FC4 2 D20:D19
HET 00 00 00 Horizontal enhancer TEXT
FC4 2 D20:D19
*** LTI ***
M04 VE1 03 03 03
Vertical enhancer DYNAMIC FC4 2 D22:D21
picture mode
VE2 03 03 03
Vertical enhancer DYNAMIC-
VIDEO
FC4 2 D22:D21
VE3 03 03 03
Vertical enhancer NATURAL FC4 2 D22:D21
VE4 03 03 03
Vertical enhancer NATURAL-
VIDEO
FC4 2 D22:D21
VE5 03 03 03
Vertical enhancer CINEMA FC4 2 D22:D21
VE6 03 03 03
Vertical enhancer CINEMA-
VIDEO
FC4 2 D20:D19
VET 00 00 00 Vertical enhancer TEXT
FC4 2 D22:D21
M05> BGT 00 00 00
Brightness/Gradation PDP 27&28 D2&D2
CCT 00 00 00
NTSC/EBU PDP 27&28 D1&D1
TCR 01 01 01
Tracking correction W/B
Warm & Norm
PDP 27&28 D0&D0
DCC 00 00 00
Tracking correction W/B Cool PDP 27&28 D0&D0
WBC 00 00 00
BSO 1F 1F 1F
Black Stretch gain offset
ON&MID
FC4 7 D21:D16
***
"PDP2_service05"
no.52
SPC 00 00 00
PinP(PC W) picture contrast
offset
FC4 7 D07:D00
M06> PHC 80 80 80
Colour phase centre FC4 8 D07:D00
PHU 1A 1A 1A
PAL HUE offset (not available
if AV2 is RGB)
FC4 8 D07:D00
NHU 20 20 20
NTSC HUE offset FC4 8 D07:D00
YU6 1D 1D 1D
YCbCr / YPbPr @ 60Hz HUE
offset
FC4 8 D07:D00
