Hitachi 32PD3000E - Monitor Rear View

32PD3000E
42PD3000E
32PD3000E
42PD3000E
(PC+ABS)
PDP Panel Module
Assembly
POWER UNIT
SIGNAL/SOUND
Board Assembly
(ABS)
(PC+ABS)
(PC+ABS)
(ABS)
(PC+ABS)
(PC+
ABS)
(PC+ABS)
(PC+
ABS)
(AL)
Code
ABS
PC+ABS
AL
Material
ACRYLONITRILE BUTADIENE STYRENE
POLYCARBONATE+
ACRYLONITRILE BUTADIENE STYRENE
ALUMINUM
The codes in brackets shown in the wiring diagram express
the name of materials.
The key to the codes and materials is shown on the table below.
42PD3000E Monitor Block
