Hitachi 32PD3000E - 24 Way Digital Interface Cable Connection

32PD3000 / 42PD3000
66
24 way Digital Interface Cable
Connection
AVC(FC4)
P301P
DV174320-4004
PDP
1 TX2-

TX2-
2 TX2+

TX2+
3 SHIELD --- SHIELD
4 N.C. --- N.C.
5 N.C. --- N.C.
6 SCLH

SCLH
7 SDAH

SDAH
8 N.C. --- N.C.
9 TX1-

TX1-
10 TX1+

TX1+
11 SHIELD --- SHIELD
12 N.C. --- N.C.
13 N.C. --- N.C.
14 +5VAVDET

+5VAVDET
15 GND --- GND
16 HPDET

HPDET
17 TXD-

TXD-
18 TXD+

TXD+
19 SHIELD --- SHIELD
20 N.C. --- N.C.
21 N.C. --- N.C.
22 SHIELD --- SUIELD
23 TXC+

TXC+
24 TXC-

TXC-
AVC(FC4)
P302P
TC57587-01-401
PDP
1 TXD

TXD
2 RXD

RXD
3 PARITY

PARITY
4 REMO-PDP

REMO-PDP
5 AUDIO L

AUDIO L
6 AUDIO R

AUDIO R
7 PDDET

PDDET
8 AVDET2

AVDET2
