Hitachi 32PD3000E - Connections to FC4

32PD3000 / 42PD3000
69
Connections to FC4
PSF at AVC P001 at FC4
Pin
No.
PIN NAME PIN NAME IN/OUT FUNCTIONS NOTE
1 GND GND I/O I
2
C bus DATA
2 N.C. N.C. I/O I
2
C bus CLOCK
3 GND GND - GND
4 DATA DATA I/O 3 wires DATA 5V CMOS
5 CLK CLK I 3 wires CLOCK 5V CMOS
6 GND GND - GND
7 FC-ENA FC-ENA I FC micro enable 5V CMOS
8 MSC-ENA OSD-CS I MSC micro enable 5V CMOS
9 DATA OSD-DATA I 3 wires DATA 5V CMOS
10 CLK OSD-CLK I 3 wires CLOCK 5V CMOS
11 GND GND - GND
12 N.C. N.C.(2H) O 2H sync for OSD
13 N.C. K_DET I
Enable for OSD
generator
14 N.C. N.C.(2V) O 2V sync for OSD
15 N.C. KMASK I
RESET for OSD
generator
16 GND GND - GND
17
RS232C-
PDP(TxD)
32C-PDP (TXD) I RS232C-TxD 5V CMOS
18
RS232C-
PDP(RxD)
32C-PDP (RXD) O RS232C-RxD 5V CMOS
19 GND GND - GND
20 +5VSTB AVDET I PDP control
21 N.C. N.C. I MATRIX control
22 Remo-PDP Remo-PDP O
R/C command from
PDP
5V CMOS
23 GND N.C. - GND
24 PM RST PM RST I PDP control 5V CMOS
25 PD DET PD DET O PDP control 5V CMOS
26 GND GND - GND
27 MY MY I Video Y 1.4V±0.06Vp-p
28 MCb MCb I Video Cb 0.7v±0.03Vp-p
29 MCr MCr I Video Cr 0.7v±0.03Vp-p
