32PD3000 / 42PD3000
70
30 GND GND - GND
31 MH MH I Main H sync 5V CMOS
32 MV MV I Main V sync 5V CMOS
33 GND GND - GND
34 SY SY I Sub Y/G
1.4V±0.06Vp-p (Y) /
0.7Vpp±0.03Vpp (G)
35 SCb SCb I Sub Cb/B 0.7v±0.03Vp-p
36 SCr SCr I Sub Cr/R 0.7v±0.03Vp-p
37 GND GND - GND
38 SH SH I Sub H sync 5V CMOS
39 SV SV I Sub V sync 5V CMOS
40 GND GND - GND
41 GND
GND(OSD/TXT
G)
I GND
42 GND
GND(OSD/TXT
B)
I GND
43 GND
GND(OSD/TXT
R)
I GND
44 GND
GND(OSD
BLK/Ys)
I GND
45 GND GND(OSD/Ym) I GND
46 GND GND - GND
47 AUDIO L AUDIO L I Audio L typ 500mVrms
48 GND GND - GND
49 AUDIO R AUDIO R I Audio R typ 500mVrms
50 GND GND - GND
P002P at FC4
PIN
NO.
PIN NAME IN/OUT FUNCTIONS NOTE
1 FA+6.0V I 6V power supply 460mA
2 FA+6.0V I 6V power supply
3 GND - GND
4 GND - GND
5 FSTB+5V I Stand-by +5V 50mA
6 FSTB+5V I Stand-by +5V
7 GND - GND
