32PD3000 / 42PD3000
12
1st 2nd 3rd 4th 5th
32"
values
hex
37"
values
hex
42"
values
hex
functions Device
CI6 00 00 00
CNR input gain CINEMA-
VIDEO
FC4 2 D15:D13
CIT 00 00 00 CNR input gain TEXT
FC4 2 D15:D13
M16 OSH 109 109 109
H position - OSD
OSV 40 40 40
V position - OSD
OTH 190 190 190
H position - TEXT
OTV 40 40 40
V position - TEXT
SUR 00 00 00
SURROUND ON:1, OFF:0
CMB 01 01 01
COMB FILTER ON:1, OFF:0
MI2> M21> DCN 3E 3E 3E
DYNAMIC Contrast
DBR 80 80 80
DYNAMIC Brightness
DCL 50 50 50
DYNAMIC Colour
DPB 00 00 00
DYNAMIC Peak Brightness
0;Peak, 1:Normal
PDP 10 D6
DCM 02 02 02
DYNAMIC Contrast Mode
NORM;0, AUTO;1, DYN;2
[ ];menu related value - decimal
it is ok to display by hex
e.g. [32] is centre of CONTRAST
e.g. [63] is MAX for
CONTRAST.
DBS 1F 1F 1F
DYNAMIC Black stretch 0;off,
01~3F; level
DWB 00 00 00
DYNAMIC White Balance
0:cool, 1;normal, 2;warm
DFT 01 01 01
DYNAMIC Film Mode 0;on,
1;off
M22> NCN 38 38 38
NATURAL Contrast
NBR 80 80 80
NATURAL Brightness
NCL 48 48 48
NATURAL Colour
NPB 00 00 00
NATURAL Peak Brightness
0;Peak, 1:Normal
PDP 10 D6
NCM 01 01 01
NATURAL Contrast Mode
NORM;0, AUTO;1, DYN;2
NBS 1A 1A 1A
NATURAL Black stretch 0;off,
01~3F; level
NWB 00 00 00
NATURAL White Balance
0:cool, 1;normal, 2;warm
NFT 01 01 01
NATURAL Film Mode 0;on,
1;off
M23> TCN 3E 3E 3E
CINEMA Contrast
TBR 80 80 80
CINEMA Brightness
TCL 50 50 50
CINEMA Colour
TPB 00 00 00
CINEMA Peak Brightness
0;Peak, 1:Normal
PDP 10 D6
TCM 00 00 00
CINEMA Contrast Mode
NORM;0, AUTO;1, DYN;2
TBS 1F 1F 1F
CINEMA Black stretch 0;off,
01~3F; level
TWB 01 01 01
CINEMA White Balance
0:cool, 1;normal, 2;warm
TFT 00 00 00
CINEMA Film Mode 0;on,
1;off
M24> DGS 01 01 01
DYNAMIC Gamma Select
NGS 01 01 01
NATURAL Gamma Select
TGS 01 01 01
CINEMA Gamma Select
PGS 02 02 02
PERSONAL Gamma Select
DPM 00 00 00
DYNAMIC Picture Mode
NPM 01 01 01
NATURAL Picture Mode
TPM 01 01 01
CINEMA Picture Mode
PPM 02 02 02
PERSONAL Picture Mode
MI3> M31> MVB 0B 0B 0B
MUSIC Volume Balance
