: should be adjusted
: should be followed previous data
Function
Maximum
Adjustment Items Mode
Value
32" 42"
FORMATTER
PWB
VIDEO
PWB
TUNER
PWB
PDP
Panel
0 R DRIVE1 [TV/VIDEO/DSUB-COMP] COOL 255 255 255
1 G DRIVE1 [TV/VIDEO/DSUB-COMP] COOL 255 255 255
2 B DRIVE1
[TV/VIDEO/DSUB-COMP] COOL 255 255 255
3 R DRIVE2 [TV/VIDEO/DSUB-COMP] NORMAL 255 255 255
4 G DRIVE2
[TV/VIDEO/DSUB-COMP] NORMAL 255 255 255
5 B DRIVE2 [TV/VIDEO/DSUB-COMP] NORMAL 255 255 255
6 R DRIVE3 [TV/VIDEO/DSUB-COMP] WARM 255 255 255
7 G DRIVE3
[TV/VIDEO/DSUB-COMP] WARM 255 255 255
8 B DRIVE3 [TV/VIDEO/DSUB-COMP] WARM 255 255 255
9 R DRIVE4 [TV/VIDEO/DSUB-COMP] BLACK & WHITE 255 255 255
10 G DRIVE4
[TV/VIDEO/DSUB-COMP] BLACK & WHITE 255 255 255
11 B DRIVE4 [TV/VIDEO/DSUB-COMP] BLACK & WHITE 255 255 255
12 R DRIVE1 [DVI-PC/DVI-STB/DSUB-RGB] COOL 255 255 255
13 G DRIVE1
[DVI-PC/DVI-STB/DSUB-RGB] COOL 255 255 255
14 B DRIVE1 [DVI-PC/DVI-STB/DSUB-RGB] COOL 255 255 255
15 R DRIVE2 [DVI-PC/DVI-STB/DSUB-RGB] NORMAL 255 255 255
16 G DRIVE2 [DVI-PC/DVI-STB/DSUB-RGB] NORMAL 255 255 255
17 B DRIVE2 [DVI-PC/DVI-STB/DSUB-RGB] NORMAL 255 255 255
18 R DRIVE3
[DVI-PC/DVI-STB/DSUB-RGB] WARM 255 255 255
19 G DRIVE3 [DVI-PC/DVI-STB/DSUB-RGB] WARM 255 255 255
20 B DRIVE3 [DVI-PC/DVI-STB/DSUB-RGB] WARM 255 255 255
21 R DRIVE4
[DVI-PC/DVI-STB/DSUB-RGB] BLACK & WHITE 255 255 255
22 G DRIVE4 [DVI-PC/DVI-STB/DSUB-RGB] BLACK & WHITE 255 255 255
23 B DRIVE4 [DVI-PC/DVI-STB/DSUB-RGB] BLACK & WHITE 255 255 255
24 Black Level(RGB
_
AMP) TV/VIDEO 254 127 127
25 Black Level(RGB
_
AMP) PC 254 127 127
26 Reference Amplitude(RGB
_
AMP) TV/VIDEO 254 127 127
27 Reference Amplitude(RGB
_
AMP) PC 254 127 127
28 Display for Max. Amplitude Level Main - - -
29 Display for Max. Amplitude Level SUB - - -
30 SUB
_
CONTRAST (RF) MAIN 15 8 8
31 SUB
_
CONTRAST (AV1) MAIN/SUB COMPOSITE mode 15 7 7
32 SUB
_
CONTRAST (RF) SUB 15 8 8
33 SUB
_
CONTRAST (AV4) MAIN/SUB COMPOSITE mode 15 7 7
34 SUB
_
COLOR (VIDEO-PAL/SECAM) MAIN 15 6 6
35 SUB
_
COLOR (RF-PAL/SECAM) MAIN 15 8 8
36 SUB
_
COLOR (VIDEO-NTSC) MAIN 15 8 8
37 SUB
_
COLOR (RF-NTSC) MAIN 15 6 6
38 SUB
_
COLOR (VIDEO-PAL/SECAM) SUB 15 8 8
39 SUB
_
COLOR (RF-PAL/SECAM) SUB 15 8 8
40 SUB
_
COLOR (VIDEO-NTSC) SUB 15 8 8
41 SUB
_
COLOR (RF-NTSC) SUB 15 8 8
42 TINT (VIDEO) MAIN 63 33 33
43 TIN
T (RF) MAIN 63 33 33
44 TINT (VIDEO) SUB 63 33 33
45 TINT (RF) SUB 63 33 33
46 S
_
B-Y
_
ADJ MAIN 15 8 8
47 S
_
R-Y
_
ADJ MAIN 15 8 8
48 S
_
B-Y
_
ADJ SUB 15 8 8
49 S
_
R-Y
_
ADJ SUB 15 8 8
50 BPF
_
Q (4.43MHz) MAIN 3 3 3
51 BPF
_
f0 (4.43MHz) MAIN 3 1 1
52 Y
_
DL (4.5MHz) MAIN 10 5 5
53 Y
_
DL (5.5MHz PAL/NTSC4.43) MAIN 10 3 3
54 Y
_
DL (5.5MHz SECAM) MAIN 10 0 0
55 Y
_
DL (6.0PAL/NTSC4.43) MAIN 10 9 9
56 Y
_
DL (6.0SECAM) MAIN 10 9 9
57 Y
_
DL (VIDEO PAL/NTSC4.43) MAIN 10 6 6
58 Y
_
DL (VIDEO SECAM) MAIN 10 8 8
59 Y
_
DL (VIDEO NTSC) MAIN 10 6 6
60 BELL
_
f0 MAIN 1 0 0
61 Y
_
OUT
_
LEVEL (VIDEO) MAIN 63 13 13
62 Free
63 Y
_
OUT
_
LEVEL (TEXT) MAIN 63 0 0
64 C
_
OUT
_
LEVEL (VIDEO) MAIN 63 7 7
65 Free
66 C
_
OUT
_
LEVEL (TEXT) MAIN 63 0 0
67 Y
_
OUT
_
LEVEL (TEXT) SUB 63 12 12
68 Y
_
OUT
_
LEVEL (VIDEO) SUB 63 13 13
69 Free
70 C
_
OUT
_
LEVEL (TEXT) SUB 63 7 7
71 C
_
OUT
_
LEVEL (VIDEO) SUB 63 7 7
72 Free
73 BPF
_
Q (4.43MHz) SUB 3 3 3
74 BPF
_
f0 (4.43MHz) SUB 3 1 1
75 Y
_
DL (4.5MHz) SUB 10 5 5
76 Y
_
DL (5.5MHz PAL/NTSC4.43) SUB 10 2 2
77 Y
_
DL (5.5MHz SECAM) SUB 10 0 0
78 Y
_
DL (6.0PAL/NTSC4.43) SUB 10 7 7
79 Y
_
DL (6.0SECAM) SUB 10 10 10
80 Y
_
DL (VIDEO PAL/NTSC4.43) SUB 10 8 8
81 Y
_
DL (VIDEO SECAM) SUB 10 6 6
82 Y
_
DL (VIDEO NTSC) SUB 10 5 5
83 BELL
_
f0 SUB 1 0 0
84 C
_
TRAP
_
SW (COMB=OFF-PAL/NTSC4.43/NTSC3.58) MAIN 1 0 0
85 C
_
TRAP
_
SW (COMB=OFF-PAL/NTSC4.43/NTSC3.58) SUB 1
1
0 0
86 MVM (VIDEO
) - 0 0
87 AFC
_
GAIN (AV00) - 3 0 0
88 AFC
_
GAIN (AV1) - 3 0 0
Defaul
t Changed Component
For Asia
For Asia
For Asia
For Asia
For Asia
For Asia
For Asia
For Asia
For Asia
For Asia
ADJ.
No.
To Next Page
