32PD5000/42PD5000 (PW1)
17
32PD5000/42PD5000 (PW1)
: should be adjusted
: should be followed previous data
Function
Maximum
Adjustment Items Mode
Value
32" 42"
VIDEO
PWB
TUNER
PWB
PDP
Panel
89 AFC
_
GAIN (AV2) - 3 0 0
90 AFC
_
GAIN (AV3) - 3 0 0
91 AFC
_
GAIN (AV4) - 3 0 0
92 S
_
INHBT - 1
1
0 0
93 S
_
ID - 0 0
94 S
_
GP - 3 0 0
95 S
_
V
_
ID - 1 0 0
96 BELL/HPF - 3 3 3
97 Cb offset1 MAIN 15 8 8
98 Cr offset1 MAIN 15 8 8
99 Cb offset1 SUB 15 8 8
100 Cr offset1 SUB 15 8 8
101 Sharpness Gain(VIDEO) PAL MAIN 15 8 8
102 Sharpness Gain(RF) MAIN 15 8 8
103 Sharpness EQ(4.5MHz) MAIN 3 1 1
104 Sharpness EQ(5.5MHz) MAIN 3 1 1
105 Sharpness EQ(6.0/6.5MHz) MAIN 3 1 1
106 Sharpness EQ(VIDEO) MAIN 3 1 1
107 Sharpness f0(VIDEO) PAL MAIN 3 2 2
108 Sharpness f0(RF) MAIN 3 2 2
109 Sharpness Gain(VIDEO) PAL SUB 15 9 9
110 Sharpness Gain(RF) SUB 15 10 10
111 Sharpness EQ(4.5MHz) SUB 3 1 1
112 Sharpness EQ(5.5MHz) SUB 3 1 1
113 Sharpness EQ(6.0/6.5MHz) SUB 3 1 1
114 Sharpness EQ(VIDEO) SUB 3 1 1
115 Sharpness f0(VIDEO) PAL SUB 3 2 2
116 Sharpness f0(RF) SUB 3 2 2
117 LPF MAIN 1 0 0
118 LPF SUB 1 0 0
119 SECAM D-Trap MAIN/SUB 1 1 1
120 FILTER SW(RF) MAIN 1 0 0
121 FILTER SW(RF) SUB 1 0 0
122 NTSC Comb(Comb off) SUB 1 1 1
123 HS Phase MAIN 1 0 0
124 HS Phase SUB 1 0 0
125 P/N ID MAIN 1 0 0
126 P/N ID SUB 1
1
0 0
127 Y/C
_
SEP
_
MODE (COMB=OFF-PAL) - 3 0 0
128
Y-P
f
0
- 0 0
129 Y-EQ
_
GAIN - 3 2 2
130 Y-EQ/N.C
_
LIM - 3 0 0
131 Y-LPF - 1 0 0
132 V-EMPH
_
GAIN - 7 1 1
133 V-EMPH
_
N.L - 7 3 3
134 V-EMPH
_
CORE - 3 3 3
135 D RANGE - 1 0 0
136 DY
_
GAIN MAIN NTSC mode 15 9 9
137 DC
_
GAIN MAIN NTSC mode 15 6 6
138 VAP
_
GAIN MAIN NTSC mode 7 2 2
139 VAP
_
INV MAIN NTSC mode 31 10 10
140 YH
_
CORE MAIN NTSC mode 3 0 0
141 YHCGAIN MAIN NTSC mode 1 1 1
142 CDL MAIN NTSC mode 7 3 3
143 YNRK MAIN NTSC mode 1 1 1
144 YNRINV MAIN NTSC mode 1 0 0
145 YNRLIM MAIN NTSC mode 3 1 1
146 CNRK 1 1 1
147 CNRINV 1 0 0
148 CNRLIM 3 1 1
149 YPFG 15 10 10
150 SEPA
_
LEVEL 480i/576i 3 2 2
151 SEPA
_
LEVEL 480p/576p 3 2 2
152 SEPA
_
LEVEL 1080i
_
50 3 2 2
153 SEPA
_
LEVEL 1080i
_
60/720p 3 2 2
154 AUTO
_
FM/AM(D11-D8) - 15 2 2
155 AUTO
_
FM/AM(D7-D0) - 254 189 189
156 A2
_
THRESHOLD(D11-D8) - 15 0 0
157 A2
_
THRESHOLD(D7-D0) - 254 112 112
158 PRE
_
AM except 4.5MHz(except BIL/STE) 254 17 17
159 VOL
_
SCART1 (D15-D8) - 254 115 115
160 VOL
_
SCART1 (D7-D5) - 7 0 0
161 PRE
_
SCART - 254 31 31
162 PRE
_
FM 4.5MHz(JAPAN) 254 34 34
163 PRE
_
FM 4.5MHz(except BTSC-SAP) 254 32 32
164 PRE
_
FM 4.5MHz(BTSC-SAP) 254 60 60
165 PRE
_
FM 4.5MHz(KOREA-except BIL/STE) 254 19 19
166 PRE
_
FM 4.5MHz(KOREA-BIL/STE) 254 34 34
167 PRE
_
FM except 4.5MHz(except BIL/STE) 254 17 17
168 PRE
_
FM except 4.5MHz(BIL/STE) 254 27 27
169 PRE
_
NICAM - 254 57 57
170 Screen Saver -Picture shift amount 0:1pixel 1:2pixels 2:3pixels 2 0 0
171 Thermal Sensor available 0:NO 1:YES 1 0 0
172 Video In
put Function available 0:NO 1:YES 1 1 1
173 Screen Saver -Picture Shift direction 0:dia 1:cross 2:up/down 3:left/right 3 0 0
174 AUDIO Function available 0 :NO, 1 :YES 1 1 1
175 Remouto Function available
0:NO, 1 :YES 1 1 1
176 Power Save On/Off Setting at Initialize,Reset and Shipping 0:Change 1: Don't Change 1 0 0
177 DVI-STB/RGB-COMPONENT Function available 0 :NO, 1 :YES 1 0 0
Defaul
t Changed Component
ADJ.
No.
FORMATTER
PWB
