Hitachi 32PD5000 - Page 18

18
32PD5000/42PD5000 (PW1)
15
32PD5000/42PD5000 (PW1)
: should be adjusted
: should be followed previous data
Function
Maximum
Adjustment Items Mode
Value
32" 42"
VIDEO
PWB
TUNER
PWB
PDP
Panel
178 Free
179 Free
180 Terminal Mode Function available 0:Not Available, 1:Available RS232C 1 0 0
181 Free
182 AGC
_
LEVEL AGCL ALL Mode 3 0 0
183 TEXT H sync delay - 127 0 0
184 TEXT V sync delay - 127 50 50
185 TEXT
_
H
_
POSITION - 254 42 42
186 TEXT
_
V
_
POSITION - 254 38 38
187 Lower Limits value for Sync Detect of 2ms interval For AFC at TV mode 254 25 25
188 Upper Limits Value for Sync Detect of 2ms interval For AFC at TV mode 254 40 40
189 Lower Limits value for Sync Detect of 2ms interval For Free Running at TV mode 254 30 30
190 Upper Limits Value for Sync Detect of 2ms interval For Free Running at TV mode 254 45 45
191 Lower Limits value for Sync Detect of 2ms interval For AUTO OFF at TV mode 254 25 25
192 Upper Limits Value for Sync Detect of 2ms interval For AUTO OFF at TV mode 254 35 35
193 Lower Limits value for Sync Detect of 2ms interval For Free Running at AV mode 254 30 30
194 Upper Limits Value for Sync Detect of 2ms interval For Free Running at AV mode 254 45 45
195 Counting time for discrimination of fV (TB1274) - 31 2 2
196 Free 1 0 0
197 Counting time for discrimination of Sync. (M30625/TA1370) - 31 2 2
198 Input Source of fV/fH judgment (0:M30625,1:TA1370) Component Mode 1 0 0
199 Counting time for discrimination of fV (M30625/TA1370) - 31 2 2
200 Y
_
DL (6.5MHz PAL/NTSC4.43) Main 10 7 7
201 Y
_
DL (6.5MHz SECAM) Main 10 10 10
202 Y
_
DL (6.5MHz PAL/NTSC4.43) Sub 10 4 4
203 Y
_
DL (6.5MHz SECAM) Sub 10 10 10
204 PDP-BLK ON/OFF 1:ON, 0:OFF 1 0 0
205 Counting time for discrimination of fH (M30625/TA1370) - 31 2 2
206 Sharpness f0(L) Sub 3 2 2
207 NJW1320
_
OUT1
_
GAIN VIDEO PWB 1 0 0
208 NJW1320
_
OUT2
_
GAIN VIDEO PWB 1 0 0
209 Sharpness f0(L') Sub 3 2 2
210 AFC
_
GAIN (Except AV00 mode) Except AV00 mode 3 0 0
211 Timer Correction
(for error of ceramic-filter osc.freq.) 62 34 34
212 Brightness Center (CM)
NT2/NT3/HD2/HD3/PAL2/PAL3/HD9/HD10/NT4/PAL4
254 128 128
213 Brightness Center (CM) HD1/HD4/HD5/HD6/HD7/HD8 254 124 124
214 Brightness Center (CM) MULTI PICTURE/NT1/PAL1 254 128 128
215 Free
216 Contrast Center (CM) TV/VIDEO(AV1/AV4 mode) 254 137 137
217 Free
218 Color Center (CM) NT1/NT2/NT4/HD3/HD4/HD6/PAL4 127 80 80
219 Color Center (CM) PAL1/PAL2/HD8/HD9 127 80 80
220 Color Center (CM) NT3/HD1/HD2/HD5/PAL3/HD7/HD10 127 80 80
221 Tint Cente
r (CM) PAL1 254 118 118
222 Tint Center (CM) NT1/NT2/NT4/HD3/HD4/HD6 254 120 120
223 Tint Center (CM) PAL2/HD8/HD10/PAL4 254 115 115
224 Tint Cente
r (CM) NT3/HD1/HD2/HD5/PAL3/HD7/HD9 254 124 124
225 Center of Sharpness (HV Enhancer Gain for Y) For Europe TV 31 19 19
226 Center of Sharpness (HV Enhancer Gain for Y) For Europe VIDEO 31 18 18
227 Center of Sharpness (HV Enhancer Gain for Y) For Europe HD5/HD6 31 11 11
228 Center of Sharpness (HV Enhancer Gain for Y) For Europe HD1/HD4/HD7/HD8 31 7 7
229 Center of Sharpness (HV Enhancer Gain for Y) For Europe HD2/HD3/HD9/HD10 31 15 15
230 Center of Sharpness (HV Enhancer Gain for Y) For Europe NT2/NT3/PAL2/PAL3/NT4/PAL4 31 15 15
231 Center of Sharpness (HV Enhancer Gain for Y) For Europe TEXT(2 picture) 31 7 7
232 Maximum Value of Contrast at REAL/NORMAL mode 254 188 188
233 Offset Value of Contrast data at SPLIT mode 120 90 90
234 Offset value of gain for Black Stretch function except OFF/LOW/HIGH 63 33 33
235 Demonstration [White] 0-3:None 4:0 5:+10W 6:+20W 7:+30W Mode(common) 7 5 5
236 Demonstration 0:Normal 1:Peak Mode 1 1 -
237 Demonstration [Middle] 0:+0W 1:+10W 2:+20W 3:+30W Mode(common) 3 3 3
238 Demonstration 0:Normal 1:Peak Mode 1 - 0
239 Horizontal Enhance TEXT 3 3 3
240 YNR Input Level at Low level for DVI-STV Mode 1080i-60/1080i-50/720p-60 7 2 2
241 YNR Input Level at Low level for DVI-STV Mode 480i/480p/576i/576p/VGA 7 2 2
242 CNR Input Level at Low level for DVI-STV Mode 1080i-60/1080i-50/720p-60 7 2 2
243 CNR Input Level at Low level for DVI-STV Mode 480i/480p/576i/576p/VGA 7 2 2
244 Vertical Enhance TEXT 3 3 3
245 Demonstration Mode 0:off 1:on 1 0 0
246 Free
247 Free
248 HV Enhancer Gain for C TEXT 31 0 0
249 YNR(NR) Input Level RF Mode 7 1 1
250 YNR Input Level at Low level for AV1-4 Mode VIDEO 7 3 3
251 YNR Input Level at Low level for AV1-4 Mode NT2/NT3/PAL2/PAL3/NT4/PAL4 7 3 3
252 YNR Input Level at Low level for AV1-4 Mode HD1/HD4/HD5/HD6/HD7/HD8 7 3 3
253 YNR Input Level at Low level for AV1-4 Mode HD2/HD3/HD9/HD10 7 3 3
254 CNR Input Level at Low level for AV1-4 Mode VIDEO 7 3 3
255 CNR Input Level at Low level for AV1-4 Mode NT2/NT3/PAL2/PAL3/NT4/PAL4 7 3 3
256 CNR Input Level at Low level for AV1-4 Mode HD1/HD4/HD5/HD6/HD7/HD8 7 3 3
257 CNR Input Level at Low level for AV1-4 Mode HD2/HD3/HD9/HD10 7 3 3
258 Heat APC function available
0:NO, 1: YES 1 1 1
259 Gamma SW (0:1.0 1:2.2 2:2.8) TV/VIDEO 2 1 1
260 Gamma SW (0:1.0 1:2.2 2:2.8) DVI-PC/DVI-STB/DSUB-RGB 2 1 1
261 Select for APC function 1 0 0
262 "CCFMD" function TV/VIDEO 1 0 0
263 "CCFMD" function DVI-PC/DVI-STB/DSUB-RGB 1 0 0
264 NTSC/EBU(CCFORM)
NT1/NT2/HD3/HD4/HD6/HD8/HD10/PAL1/PAL2
1 0 0
265 NTSC/EBU(CCFORM)
TV/VIDEO/NT3/PAL3/HD1/HD2/HD5/HD7/HD9/NT4/PAL4
1 0 0
266 NTSC/EBU(CCFORM) DVI-PC/DVI-STB/DSUB-RGB 1 0 0
