: should be adjusted
: should be followed previous data
Function
Maximum
Adjustment Items Mode
Value
32" 42"
VIDEO
PWB
TUNER
PWB
PDP
Panel
356 SEPA
_
LEVEL
_
DSUB 480i/576i 3 2 2
357 SEPA
_
LEVEL
_
DSUB 480p/576p 3 2 2
358 SEPA
_
LEVEL
_
DSUB 1080i_50 3 2 2
359 SEPA
_
LEVEL
_
DSUB 1080i_60/720p 3 2 2
360 HD-PHASE
_
DSUB 480i/576i 63 20 20
361 HD-PHASE
_
DSUB 480p/576p 63 20 20
362 HD-PHASE
_
DSUB 1080i_50 63 20 20
363 HD-PHASE
_
DSUB 1080i_60/720p 63 20 20
364 Y
_
DL (L) MAIN 10 4 4
365 Y
_
DL (L') MAIN 10 4 4
366 Y
_
DL (L) Sub 10 1 1
367 Y
_
DL (L') Sub 10 1 1
368 Sharpness Gain(L) MAIN 15 10 10
369 Sharpness Gain(L') MAIN 15 10 10
370 Sharpness Gain(L) SUB 15 8 8
371 Sharpness Gain(L') SUB 15 8 8
372 Sharpness f0(L) MAIN 3 2 2
373 Sharpness f0(L') MAIN 3 2 2
374 BURN-IN enable/ disenable 0:Disenable, 1:Enable 1 1 1
375 BURN-IN mode 2 2 2
376 CM
_
THRESHOLD (D15-D8) - 254 0 0
377 CM
_
THRESHOLD (D7 -D0) - 254 36 36
378 Sharpness Gain(RF M) MAIN 15 11 11
379 Sharpness Gain(RF M) Sub 15 11 11
380 Sharpness f0 (RF M) Main 3 2 2
381 Sharpness f0 (RF M) SUB 3 2 2
382 Counting Value of 2ms Sync.Detect MAIN - - -
383 Counting Value of 2ms Sync.Detect SUB - - -
384 TB1274 Read Data(00h) Main - - -
385 TB1274 Read Data(01h) Main - - -
386 TB1274 Read Data(00h) Sub - - -
387 TB1274 Read Data(01h) Sub - - -
388 MSP Read Data (CNTROL ) (D15-D8 ) - - -
389 MSP Read Data (CNTROL ) (D7 -D0 ) - - -
390 MSP Read Data (STANDARD_RES) (D15-D8 ) - - -
391 MSP Read Data (STANDARD_RES) (D7 -D0 ) - - -
392 MSP Read Data (STATUS ) (D15-D8 ) - - -
393 MSP Read Data (STATUS ) (D7 -D0 ) - - -
394 TA1370G Read Data(00h) VIDEO PWB - - -
395 TA1370G Read Data(01h) VIDEO PWB - - -
396 TA1370G Read Data(00h) FORMATTER PWB - - -
397 TA1370G Read Data(01h) FORMATTER PWB - - -
398 uPD64084 Read Data(00H) - - -
399 uPD64084 Read Data(01h) - - -
400 Language (Refer to below) 6 0 0
401 Hotel Mode(0:No,1:Yes) 1 0 0
402 Analog Data (0:Keep EEPROM,1:Not Keep to EEPROM) 1 0 0
403 Maximum Volume Limit 63 63 63
404 Power Mode(0:Last mode, 1:Pos1, 2:V1, 3:V2, 4:V3, 5:V4) 5 0 0
405 Channel Select(0:CCIR, 1:CHINA) 1 0 0
406 Auto_sound 4.5 (0:Korea, 1:BTSC, 2:Japan) 2 0 0
407 T/TEXT(0: None, 1:Yes) 1 1 1
408 TEXT Language 7 0 0
409 IIC BUS Data/Clock Open(0:Close, 1:Open) 1 0 0
410 Channel Preset(0:VESTEL, 1:GIFU, 2:HAMA, 3:HFDM,4:AUSTRALIA) 4 1 1
411 Detect and Display Tele-Cinema (0:normal 1:Tele-Cinema) - - -
412 V FREQ 60Hz Force (0:None, 1:Yes) Main/Sub 1 0 0
413 COLOR SYSTEM CONTROL-MODE
(0:BW, 2:3.58NTSC, 3:4.43NTSC,
) Main - - -
414 COLOR SYSTEM CONTROL-MODE(0:BW, 2:3.58NTSC, 3:4.43NTSC,
) Sub - - -
415 Horizontal Filter SW [HHPF0] NTSC 1 0 0
416 Enhancer Gain [HHPF1] PAL 1 0 0
417 Enhancer Gain [HHPF2] HD 1 0 0
418 Horizontal Coring Level (Enhancer Gain) AS[HECOR0_PO] NT1-RF 15 - 1
419 Horizontal Coring Level (Enhancer Gain) AS[HECOR1_PO] PAL1-RF / Multi picture 15 - 1
420 Horizontal Coring Level (Enhancer Gain) [HECOR2_PO] NT1-Video 15 - 1
421 Horizontal Coring Level (Enhancer Gain) [HECOR3_PO] PAL1-Video 15 - 1
422 Horizontal Coring Level (Enhancer Gain) [HECOR4_PO] NT2/NT3/NT4/PAL2/PAL3/PAL4 15 - 1
423 Horizontal Coring Level (Enhancer Gain) [HECOR5_PO] HD2/HD3/HD9/HD10 15 - 1
424 Horizontal Coring Level (Enhancer Gain) [HECOR6_PO] HD1/HD4/HD5/HD6/HD7/HD8 15 - 0
425 Horizontal Coring Level (Enhancer Gain) [HECORPC_PO] PC 15 - 1
426 Horizontal Coring Level (Enhancer Gain) EU[HECORE_PO] PAL1-RF / Multi picture 15 - 1
427 Vertical Coring Level (Enhancer Gain) AS[VECOR0_PO] NT1-RF 15 - 1
428 Vertical Coring Level (Enhancer Gain) AS[VECOR1_PO] PAL1-RF / Multi picture 15 - 1
429 Vertical Coring Level (Enhancer Gain) [VECOR2_PO] NT1-Video 15 - 1
430 Vertical Coring Level (Enhancer Gain) [VECOR3_PO] PAL1-Video 15 - 1
431 Vertical Coring Level (Enhancer Gain) [VECOR4_PO] NT2/NT3/NT4/PAL2/PAL3/PAL4 15 - 0
432 Vertical Coring Level (Enhancer Gain) [VECOR5_PO] HD2/HD3/HD9/HD10 15 - 0
433 Vertical Coring Level (Enhancer Gain) [VECOR6_PO] HD1/HD4/HD5/HD6/HD7/HD8 15 - 0
434 Vertical Coring Level (Enhancer Gain) [VECORPC_PO] PC 15 - 0
435 Vertical Coring Level (Enhancer Gain) EU[VECORE_PO] PAL1-RF / Multi picture 15 - 0
436 Horizontal Coring Level (Enhancer Gain) AS[HECOR0_P1] NT1-RF 15 1 -
437 Horizontal Coring Level (Enhancer Gain) AS[HECOR0_P2] PAL1-RF / Multi picture 15 1 -
438 Horizontal Coring Level (Enhancer Gain) [HECOR0_P3] NT1-Video 15 1 -
439 Horizontal Coring Level (Enhancer Gain) [HECOR0_P4] PAL1-Video 15 1 -
440 Horizontal Coring Level (Enhancer Gain) [HECOR0_P5] NT2/NT3/NT4/PAL2/PAL3/PAL4 15 1 -
441 Horizontal Coring Level (Enhancer Gain) [HECOR0_P6] HD2/HD3/HD9/HD10 15 1 -
442 Horizontal Coring Level (Enhancer Gain) [HECOR0_P7] HD1/HD4/HD5/HD6/HD7/HD8 15 0 -
443 Horizontal Coring Level (Enhancer Gain) [HECORPC_P1] PC 15 1 -
444 Horizontal Coring Level (Enhancer Gain) EU[HECORE_P1] PAL1-RF / Multi picture 15 1 -
Defaul
t Changed Component
ADJ.
No.
FORMATTER
PWB
