: should be adjusted
: should be followed previous data
Function
Maximum
Adjustment Items Mode
Value
32" 42"
VIDEO
PWB
TUNER
PWB
PDP
Panel
445 Vertical Coring Level (Enhancer Gain) AS[VECOR0
_
P1] NT1-RF 15 1 -
446 Vertical Coring Level (Enhancer Gain) AS[VECOR0
_
P2] PAL1-RF / Multi picture 15 1 -
447 Vertical Coring Level (Enhancer Gain) [VECOR0
_
P3] NT1-Video 15 1 -
448 Vertical Coring Level (Enhancer Gain) [VECOR0
_
P4] PAL1-Video 15 1 -
449 Vertical Coring Level (Enhancer Gain) [VECOR0
_
P5] NT2/NT3/NT4/PAL2/PAL3/PAL4 15 0 -
450 Vertical Coring Level (Enhancer Gain) [VECOR0
_
P6] HD2/HD3/HD9/HD10 15 0 -
451 Vertical Coring Level (Enhancer Gain) [VECOR0
_
P7] HD1/HD4/HD5/HD6/HD7/HD8 15 0 -
452 Vertical Coring Level (Enhancer Gain) [VECORPC
_
P1] PC 15 0 -
453 Vertical Coring Level (Enhancer Gain) EU[VECORE
_
P1] PAL1-RF / Multi picture 15 0 -
454 YFRNR In
put Gain (Main) 2 pictures [MYNRG0] HD-except HD 7 1 1
455 <HD-NTSC,HD-PAL(Sub) [MYNRG1] HD-HD 7 4 4
456 4 pictures [MYNRG2] NT-*/PAL-* 7 1 1
457 [MYNRG3] HD-* 7 4 4
458 YFRNR In
put Gain (Sub) [YCNRG0] 2 pictures 7 4 4
459 [YCNRG1] 4pictures/12pictures 7 1 1
460 CFRNR Input Gain (Main) 2 pictures [MCNRG0] HD-except HD 7 3 3
461 <HD-NTSC,HD-PAL(Sub) [MCNRG1] HD-HD 7 4 4
462 [MCNRG2] NT-*/PAL-* 7 4 4
463 [MCNRG3] HD-* 7 4 4
464 CFRNR In
put Gain (Sub) [SCNRG0] 2 pictures 7 3 3
465 [SCNRG1] 4pictures/12pictures 7 4 4
466 YFRNR Transition Level (Main/Sub) [MYNRP0] NT1/ PAL1 / Multi picture 7 0 0
467 [MYNRP5] NT1/PAL1-Video 7 0 0
468 [MYNRP6] NT2/NT3/NT4/PAL2/PAL3/PAL4 7 0 0
469 [MYNRP7] HD2/HD3/HD9/HD10 7 0 0
470 [MYNRP8] HD1/HD4/HD5/HD6/HD7/HD8 7 0 0
471 CFRNR Transition Level (Main/Sub) [MCNRP0] NT1/ PAL1 / Multi picture 7 2 2
472 [MCNRP5] NT1/PAL1-Video 7 2 2
473 [MCNRP6] NT2/NT3/NT4/PAL2/PAL3/PAL4 7 2 2
474 [MCNRP7] HD2/HD3/HD9/HD10 7 2 2
475 [MCNRP8] HD1/HD4/HD5/HD6/HD7/HD8 7 0 0
476 Vertical Enhancer Gain for Y/G [YVEG0
_
P0] NTSC/PAL(-except RF) 15 - 8
477 [YVEG1
_
P0] HD2/HD3/HD9/HD10 15 - 12
478 [YVEG2
_
P0] HD1/HD4/HD5/HD6/HD7/HD8 15 - 8
479 AS[YVEG3
_
P0] PAL1-RF / Multi picture 15 - 8
480 EU[YVEG0
_
E
_
P0] PAL1-RF / Multi picture 15 - 8
481 Vertical DSB Gain For Y/G [YVDSBG0
_
P0] NTSC/ PAL / Multi picture 3 - 0
482 [YVDSBG1
_
P0] HD2/HD3/HD9/HD10 3 - 0
483 [YVDSBG2
_
P0] HD1/HD4/HD5/HD6/HD7/HD8 3 - 0
484 Vertical DSB Coring for Y/G [YVDSBG0
_
P0] NTSC/ PAL / Multi picture 7 - 0
485 [YVDSBG1
_
P0] HD 7 - 3
486 Vertical Enhancer Clip for Y/G 0:LTI [YVECLP0
_
P0] NTSC/ PAL / Multi picture 1 - 1
487 [YVECLP1
_
P0] HD 1 - 1
488 Vertical Clip Offset Level [YVECLP0
_
P0] NTSC/ PAL / Multi picture 15 - 7
489 [YVECLP1
_
P0] HD 15 - 1
490 Vertical Non Linear Peaking for Y/G [YVNLP0
_
P0] NTSC/ PAL / Multi picture 63 - 0
491 [YVNLP1
_
P0] HD 63 - 0
492 Horizontal HPF Peak Freq. SW for Y/G [YHHPF0
_
P0] NTSC/ PAL / Multi picture 3 - 2
493 [YHHPF1
_
P0] HD2/HD3/HD9/HD10 3 - 1
494 [YHHPF2
_
P0] HD1/HD4/HD5/HD6/HD7/HD8 3 - 1
495 Horizontal Enhancer Gain for Y/G [YHEG0
_
P0] NTSC/PAL(-except RF) 15 - 15
496 [YHEG1
_
P0] HD2/HD3/HD9/HD10 15 - 15
497 [YHEG2
_
P0] HD1/HD4/HD5/HD6/HD7/HD8 15 - 0
498 AS[YHEG3
_
P0] PAL1-RF / Multi picture 15 - 15
499 EU[YHEG0
_
E
_
P0] PAL1-RF / Multi picture 15 - 15
500 Horizontal DSB Gain For Y/G [YHDSBG0
_
P0] NTSC/ PAL / Multi picture 3 - 2
501 [YHDSBG1
_
P0] HD2/HD3/HD9/HD10 3 - 0
502 [YHDSBG2
_
P0] HD1/HD4/HD5/HD6/HD7/HD8 3 - 0
503 Horizontal DSB Coring for Y/G [YHDSBC0
_
P0] NTSC/ PAL / Multi picture 7 - 4
504 [YHDSBC1
_
P0] HD 7 - 0
505 Horizontal Enhancer Clip for Y/G 0:LTI [YHECLP0
_
P0] NTSC/ PAL / Multi picture 1 - 0
506 [YHECLP1
_
P0] HD 1 - 0
507 Horizontal Clip Offset Level for Y/G AS[YHECLPL0
_
P0] RF / Multi picture 15 - 2
508 AS[YHECLPL1
_
P0] NT1-except RF / PAL1-except RF 15 - 2
509 [YHECLPL2
_
P0] HD 15 - 1
510 EU[YHECLPL0
_
E
_
P0] RF / Multi picture 15 - 4
511 EU[YHECLPL1
_
E
_
P0] NT1-except RF / PAL1-except RF 15 - 4
512 Horizontal Non Linear Peaking for Y/G [YHNLP0
_
P0] NTSC/ PAL / Multi picture 63 - 0
513 [YHNLP1
_
P0] HD 63 - 0
514 Coring Amplitude for Y/G [YCOR0
_
PO] NT1-RF/ PAL1-RF / Multi picture 7 - 7
515 [YCOR1
_
PO] NT1-Video / PAL1-Video 7 - 5
516 [YCOR2
_
PO] NT2/NT3/NT4/PAL2/PAL3/PAL4 7 - 3
517 [YCOR3
_
PO] HD2/HD3/HD9/HD10 7 - 1
518 [YCOR4
_
PO] HD1/HD4/HD5/HD6/HD7/HD8 7 - 1
519 Vertical Enhancer Gain for Y/G [YVEG0
_
P1] NTSC/PAL(-except RF) 15 8 -
520 [YVEG1
_
P1] HD2/HD3/HD9/HD10 15 12 -
521 [YVEG2
_
P1] HD1/HD4/HD5/HD6/HD7/HD8 15 8 -
522 AS[YVEG3
_
P1] PAL1-RF / Multi picture 15 8 -
523 EU[YVEG0
_
E
_
P1] PAL1-RF / Multi picture 15 8 -
524 Vertical DSB Gain for Y/G [YVDSBG0
_
P1] NTSC/ PAL / Multi picture 3 0 -
525 [YVDSBG1
_
P1] HD2/HD3/HD9/HD10 3 0 -
526 [YVDSBG2
_
P1] HD1/HD4/HD5/HD6/HD7/HD8 3 0 -
527 Vertical DSB Coring for Y/G [YVDSBC0
_
P1] NTSC/ PAL / Multi picture 7 0 -
528 [YVDSBC1
_
P1] HD 7 3 -
529 Vertical Enhancer Clip for Y/G 0:LTI [YVECLP0
_
P1] NTSC/ PAL / Multi picture 1 1 -
530 [YVECLP1
_
P1] HD 1 1 -
531 Vertical Clip Offset Level for Y/G [YVECLP0
_
P1] NTSC/ PAL / Multi picture 15 7 -
532 [YVECLP1
_
P1] HD 15 1 -
533 Vertical Non Linear Peaking for Y/G [YVNLP0
_
P1] NTSC/ PAL / Multi picture 63 0 -
Defaul
t Changed Component
ADJ.
No.
FORMATTER
PWB
