Hitachi 32PD5000 - Page 63

JOINT board ( side-A )
JOINT board ( side-B )
Cir.No. Position Cir.No. Position
DH98 A4 IF08 F4
DH99 A4 KH101 B5
EJF1 E5 KH102 A5
EJF2 F5 LH101 D5
EJF3 G2 LH101A D5
EJF4 C3 PCL1 G3
EJF5 G4 PTEM1 A5
EJF6 G3
Mainly chip parts reference table
