Hitachi 32PD5000 - Page 76

76
37PD5200 (EU) (PW1)
POWER UNIT
SP TERMINAL R PWB
AUDIO PWB
FORMATTER UNIT
SP TERMINAL L PWB
To previous page
FILTER
PWB
POW SW
LED/RECEIVER PWB
TACT SW PWB
No.18
ECONT
TACT SW PWB
6
1
6
1
NVS10
Detail of (*5)
EFJ3
No.12
NVS1
EJF3
Detail of (*7)
(Green)
(Black)
(White)
Detail of (*8)
Pass No.12 connector through NVS1.
Insert it in EJF3/EFJ3 and push the stopper down to lock.
50P Flat cable
stopper
blue band
electrode side
JOINT PWB
FORMATTER PWB
Flat core
PPU1 CN61
Detail of (*6)
Faston connector with Lock:
Connect it completely to be locked.
Disconnect it pushing the button to release the lock.
GND
L
N
2
1
(black)
(white)
E901
SUP-C14608
Aview
Bview
LABEL
E902
E903
Aview
Bview
Wiring diagram 2/2
