5.5 WHITE BALANCE ADJUSTMENT OSD FLOW DIAGRAM
BACK TO ADJUSTMENTS
5.5.1 Adjustment OSD Flowchart
(1) Adjust Mode OSD
JIG R/C code:9C or Press [MENU]+[MENU]+[8]+[SELECT] of Control panel.
MENU
+
MENU
+
8
+
SELECT
JIG Code
ADJUST MODE
FACT RESET
MEMORY INIT
RGB
WHITE BAL HIGH
WHITE BAL MED
WHITE BAL STD
WHITE BAL B/W
CH U/D, INPUT


ًٕ
ًٕ
ًٕ
 CYAN*


GREEN : Finish Normally

RED : Finish Abnormally




 


EXIT
Press
for 2 seg.
ADJUST MODE
FACT RESET
MEMORY INIT
RGB
WHITE BAL HIGH
WHITE BAL MED
WHITE BAL STD
WHITE BAL B/W
CH U/D, INPUT
ADJUST MODE
FACT RESET
MEMORY INIT
RGB
WHITE BAL HIGH
WHITE BAL MED
WHITE BAL STD
WHITE BAL B/W
CH U/D, INPUT
MAGENTA


GREEN : Finish Normally
RED : Finish Abnormally




 


Press for 2 seg.
Press
for 2 seg.
CH 3
