13 EN
Antenna connections
If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you
are using a Cable TV service, see Cable TV connections.
Combination VHF/UHF Antenna (Single 75 ohm cable)
75 ohm
Coaxial
Cable
Antenna
Jack
Cable TV connections
For subscribers to scrambled Cable TV service
For subscribers to unscrambled Cable TV service with scrambled premium channels
This TV has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some
cable companies oer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal
viewing requires the use of a descrambler device which is generally provided by the Cable TV company.
For subscribers to basic Cable TV service
C
C
75 ohm
Coaxial Cable
Antenna
Jack
75 ohm
Coaxial Cable
Antenna
Jack
75 ohm
Coaxial Cable
Antenna
Jack
To Next Page
