PARTS LIST-FOR AUSTRALIA AND NEW ZEALAND
15 in. (380mm) DRILL PRESS PARTS LIST MODEL NO. B16RM
PARTS LIST FOR SCHEMATIC Always order by I.D. Number
Parts No. I.D. Description Size QTY Parts No. I.D. Description Size QTY
726323 0607 SWITCH BOX 1 726521 0JKH V-BELT 1
726359 04A4 CLAMP-CORD 3 726528 0JQ0 HEX. HD. BOLT M10*1.5-40 4
726360 04Q4 STICKER 1 325850 0JXL HEX. SOC. SET SCREW M10*1.5-12 2
726361 056T COLUNM ASS’Y 1 726535 0K17 HEX. HD. SCREW AND WASHER M8*1.25-20 4
726362 058W MOTOR PULLEY ASS’Y 1 726557 0K7K CR. RE. ROUND WASHER HD. SCREW M6*1.0-12 5
726363 05UE BASE 1 726564 0K94 CR. RE. TRUSS HD. TAPPING SCREW M5*12-16 2
326389 05UW WORM 1 726579 0KDH CR. RE. PAN HD. SCREW M5*0.8-8 3
726364 05UX CRANK HANDLE ASS’Y 1 726580 0KDJ CR. RE. PAN HD. SCREW M5*0.8-12 3
726366 05VQ RACK 1 726582 0KDU CR. RE. PAN HD. SCREW M6*1.0-12 3
726367 05VT RACK RING ASS’Y 1 726583 0KDZ CR. RE. PAN HD. SCREW M6*1.0-35 2
726368 05WJ HANDLE SHIFTER 1 726586 0KFF CR. RE. PAN HD. SCREW M5*0.8-8 2
726369 05WL MOTOR BAR SHIFTER ASS’Y 1 726599 0KMU HEX. NUT M10*1.5 T=8 1
726370 05WN MOTOR ROD 1 726600 0KMV HEX. NUT M10*1.5 T=8 1
726371 05WR SHIFTER BOLT M10*1.5-33 2 726602 0KMX HEX. NUT M12*1.75 T=10 2
726373 05X2 FEED SHAFT ASS’Y 1 726603 0KMY HEX. NUT M8*1.25 T=6.5 4
726374 05XK SCALE RING 1 726608 0KPV HEX. NUT 1/2*20UNF T=10 1
726375 05Y0 SHAFT SEAT 1 726609 0KPX HEX. NUT 1/2*20UNF T=6.5 1
726377 05Y2 QUILL SET SCREW M10*1.5-2 1 726624 0KSQ STRAIN RELIEF φ20 2
726378 05YD SPINDLE ASS’Y 1 726627 0KUW TERMINAL 1
726379 05YN DRIVING SLEEVE ASS’Y 1 726629 0KYN LEAD WIRE ASS’Y 1
726380 05YS PULLEY SET NUT φ22.5 1 726634 0LRT ROCKER SWITCH 1
726381 05Z0 SPINDLE PULLEY 1 326395 0U3E MOTOR WIRE 1
726382 05Z2 WEDGE SHIFTER 1 326396 0U3F MOTOR 1
726383 061R CHUCK KEY HOLDER 1 326653 0U76 LASER STICKER 2
726384 061Y MOTOR ROD 1 726645 0VJK PLATE SPRING ASS’Y 1
726385 06HB PLUNGER HOUSING 1 726646 0VME CENTER PULLEY ASS’Y 1
726386 06HG CIRCULAR NUT 1 326397 0WTN BULB SOCKET ASS’Y 1
326392 06KA MOTOR BASE 1 726647 0WTQ PULLEY COVER ASS’Y 1
726388 06SV CORD-CLAMP 1 326398 0WVE TABLE 1
726389 06TS SWITCH COVER 1 326529 0X5N POWER CABLE 1
726432 08CQ WASHER φ24 T=1/16 1 326654 25Q0 WARNING LABEL 1
726433 08CR NUT M16*2.0 D=φ24 H=13 2 326399 26FE COLLAR 1
726470 0HY8 DRILLING ARBOR 1 726776 27QB TABLE LOCK HANDLE 1
726471 0J28 CHUCK & KEY 1 726777 27QC COLUMN LOCK HANDLE 1
726472 0J3M HEX. WRENCH 1 726810 28NW HANDLE BAR ASS’Y 1
726474 0J3Q HEX. WRENCH 1 726811 28P2 ROCKER SWITCH 1
726475 0J3R WRENCH HEX. 1 726821 28SZ TABLE BRACKET ASS’Y 1
326393 0J4J FLAT WASHER φ10*20 2 326400 28WJ HEAD 1
726493 0J7F FLAT WASHER 5/16*7/8-5/64 4 326655 28WX TRADE-MARK LABEL 1
726496 0J8F FLAT WASHER 1/4*3/4-3/16 4 326656 28WZ WARNING LABEL 1
726499 0J9M SPRING WASHER φ1/2 2 326657 28X0 LASER STICKER 1
726502 0JAF
EXTERNAL TOOTH LOCK WASHER φ5 2 326401 29HG LASER ASS’Y 1
726509 0JCM SPRING PIN 2 326659 2HUV LABEL 1
726516 0JG4 PARALLEL KEY 1 326658 2HUW LABEL 1
726520 0JKD V-BELT 1 326668 2HZS SET BOLT ASS’Y 1
