44
—
PARTS LIST-FOR SINGAPORE MALAYSIA INDONESIA SAUDI ARABIA
15 in. (380mm) DRILL PRESS PARTS LIST MODEL NO. B16RM
PARTS LIST FOR SCHEMATIC Always order by I.D. Number
Parts No. I.D. Description Size QTY Parts No. I.D. Description Size QTY
326402 04A5 CLAMP-CORD 1 726557 0K7K CR. RE. ROUND WASHER HD. SCREW M6*1.0-12 5
326403 04Q3 EARTH LABEL 1 326410 0KDF CR. RE. PAN HD. SCREW M5*0.8-45 4
326404 04TP LIMIT SWITCH GUARD 1 726580 0KDJ CR. RE. PAN HD. SCREW M5*0.8-12 3
326405 04TR
LIMIT SWITCH INSULATION BLOCK 1 726581 0KDR CR. RE. PAN HD. SCREW M5*0.8-10 4
326406 04UC RETAINING CLIP 1 726582 0KDU CR. RE. PAN HD. SCREW M6*1.0-12 2
326407 04UE PRESSING 1 726583 0KDZ CR. RE. PAN HD. SCREW M6*1.0-35 2
726361 056T COLUNM ASS’Y 1 326411 0KF4 CR. RE. PAN HD. SCREW M3*0.5-20 4
726362 058W MOTOR PULLEY ASS’Y 1 726586 0KFF CR. RE. PAN HD. SCREW M5*0.8-8 3
326408 058Y CORD-CLAMP 3 726599 0KMU HEX. NUT M10*1.5 T=8 1
326409 05QT INSULATE PLATE 1 726600 0KMV HEX. NUT M10*1.5 T=8 1
726363 05UE BASE 1 726602 0KMX HEX. NUT M12*1.75 T=10 2
326389 05UW WORM 1 726603 0KMY HEX. NUT M8*1.25 T=6.5 4
726364 05UX CRANK HANDLE ASS’Y 1 326412 0KNB HEX. NUT M3*0.5 T=2.4 2
726366 05VQ RACK 1 726608 0KPV HEX. NUT 1/2*20UNF T=10 1
726367 05VT RACK RING ASS’Y 1 726609 0KPX HEX. NUT 1/2*20UNF T=6.5 1
726368 05WJ HANDLE SHIFTER 1 726615 0KQW LOCK NUT M5*0.8 T=5 1
726369 05WL MOTOR BAR SHIFTER ASS’Y 1 726624 0KSQ STRAIN RELIEF φ20 2
726370 05WN MOTOR ROD 1 326413 0KT2 STRAIN RELIEF 2
726371 05WR SHIFTER BOLT M10*1.5-33 2 326414 0KVK LEAD WIRE ASS’Y 1
726373 05X2 FEED SHAFT ASS’Y 1 338504 3LAX POWER CABLE 1
726374 05XK SCALE RING 1 326530 0LF9 POWER CABLE 1
726375 05Y0 SHAFT SEAT 1 326416 0LN3 WIRE CONNECTOR 1
726377 05Y2 QUILL SET SCREW M10*1.5-2 1 726634 0LRT ROCKER SWITCH 1
726378 05YD SPINDLE ASS’Y 1 326417 0LU1 LIMIT SWITCH 1
726379 05YN DRIVING SLEEVE ASS’Y 1 326669 0U32 HEAD 1
726380 05YS PULLEY SET NUT φ22.5 1 326418 0U36 PULLEY COVER ASS’Y 1
726381 05Z0 SPINDLE PULLEY 1 326419 0U37 TENSION PLATE 1
726382 05Z2 WEDGE SHIFTER 1 326420 0U3B CONNECTOR BOX 1
726383 061R CHUCK KEY HOLDER 1 326531 0U3C LEAD WIRE ASS’Y 1
726384 061Y MOTOR ROD 1 326532 0U3D LEAD WIRE ASS’Y 1
726385 06HB PLUNGER HOUSING 1 326395 0U3E MOTOR WIRE 1
726386 06HG CIRCULAR NUT 1 326396 0U3F MOTOR 1
326392 06KA MOTOR BASE 1 326653 0U76 LASER STICKER 2
726432 08CQ WASHER φ24 T=1/16 1 726645 0VJK PLATE SPRING ASS’Y 1
726433 08CR NUT
M16*2.0 D=φ24 H=13 2 726646 0VME CENTER PULLEY ASS’Y 1
726470 0HY8 DRILLING ARBOR 1 326421 0WJE PUSH BUTTON SWITCH ASS’Y 1
726471 0J28 CHUCK & KEY 1 326397 0WTN BULB SOCKET ASS’Y 1
726472 0J3M HEX. WRENCH 1 326398 0WVE TABLE 1
726474 0J3Q HEX. WRENCH 1 326424 22QF
CR. RE. TRUSS HD. TAPPING SCREW M5*12-20 2
726475 0J3R WRENCH HEX. 1 326654 25Q0 WARNING LABEL 1
326393 0J4J FLAT WASHER φ10*20 2 326399 26FE COLLAR 1
726493 0J7F FLAT WASHER 5/16*7/8-5/64 4 726776 27QB TABLE LOCK HANDLE 1
726496 0J8F FLAT WASHER 1/4*3/4-3/16 4 726777 27QC COLUMN LOCK HANDLE 1
726499 0J9M SPRING WASHER φ1/2 2 726810 28NW HANDLE BAR ASS’Y 1
726502 0JAF
EXTERNAL TOOTH LOCK WASHER φ5 2 726821 28SZ TABLE BRACKET ASS’Y 1
726509 0JCM SPRING PIN 2 326655 28WX TRADE-MARK LABEL 1
726516 0JG4 PARALLEL KEY 1 326656 28WZ WARNING LABEL 1
726520 0JKD V-BELT 1 326657 28X0 LASER STICKER 1
726521 0JKH V-BELT 1 326401 29HG LASER ASS’Y 1
726528 0JQ0 HEX. HD. BOLT M10*1.5-40 4 326534 2GYE SWITCH BOX 1
325850 0JXL HEX. SOC. SET SCREW M10*1.5-12 2 326535 2GYS LEAD WIRE ASS’Y 1
726535 0K17 HEX. HD. SCREW AND WASHER M8*1.25-20 4 326658 2HUW LABEL 1
325717 0K35 CR.RE. PAN HD. SCREW & WASHER M5*0.8-25 1 326668 2HZS SET BOLT ASS’Y 1
726555 0K7F CR. RE. ROUND WASHER HD. SCREW M5*0.8-8 5 326670 2J7M LABEL 1
