Hitachi C 10FCH2 Technical Data And Service Manual

*
ALTERNATIVE PARTS--- 4 ---
ITEM
NO.
CODE NO.
DESCRIPTION REMARKS
NO.
USED
PARTS
10 -- 06
C 10FCH2
52 949-342 FLAT HD. SCREW M6X25 (10 PCS.) 1
53 326-704 SUB FENCE (B) 1
54 326-698 FENCE (B) 1
55 326-705 HOLDER 1
56 322-901 LINER (A) 2
57 322-964 LINER (C) 1
58 949-611 BOLT M6X12 (10 PCS.) 1
59 322-903 SPRING PLATE 1
60 949-457 SPRING WASHER M8 (10 PCS.) 2
61 949-655 HEX. SOCKET HD. BOLT M8X16 (10 PCS.) 2
62 326-826 SCALE (A) 1
63 326-696 SPACER (A) 1
64 317-200
MACHINE SCREW (W/WASHERS) M4X8 (BLACK) 1
65 326-697 FENCE (A) 1
66 322-902 SHAFT (B) 1
67 326-694 BASE ASS’Y 1 INCLUD. 62
* 100 998-335 BOLT (LEFT HAND) W/WASHER M7X17.5 1 EXCEPT FOR NZL
* 101 318-961 WASHER (A) 1 FOR EUROPE
* 101 308-789 WASHER (D) 2 FOR USA, CAN, AUS, NZL, HKG
* 101 318-962 WASHER (B) 1 FOR EUROPE
* 102 318-963
TCT SAW BLADE 255MM-D15.88 HOLE-NT24 1
* 102 319-107 TCT SAW BLADE 255MM-D30 HOLE-NT30 1
* 102 319-106 TCT SAW BLADE 255MM-D25.4 HOLE-NT24 1
* 102 318-964
TCT SAW BLADE 255MM-D25.4 HOLE-NT100 1
* 103 974-663Z COLLAR (A) FOR D30 HOLE 1 FOR EUROPE
* 103 976-819 COLLAR (B) FOR D25.4 HOLE 1 FOR AUS, NZL, HKG, CHN
104 323-133 SPINDLE ASS’Y 1 INCLUD. 105-109
105 990-430 SEAL LOCK FLAT HD. SCREW M4X10 2
106 322-919 BEARING COVER 1
107 600-3VV BALL BEARING 6003VVCMPS2L 1
108 322-918 BEARING HOLDER 1
109 322-917 SPINDLE AND GEAR SET 1
110 982-027 NEEDLE BEARING (HK1010) 1
111 987-512
MACHINE SCREW (W/SP. WASHER) M5X16 2
112 980-523 NYLON CLIP 2
113 949-429 BOLT WASHER M4 (10 PCS.) 2
114 949-215 MACHINE SCREW M4X8 (10 PCS.) 2
*115 949-819 HEX. SOCKET HD. BOLT M5X10 (10 PCS.) 1 EXCEPT FOR NZL
116 961-729 CUSHION 1
117 949-340 FLAT HD. SCREW M6X16 (10 PCS.) 1
118 949-217 MACHINE SCREW M4X12 (10 PCS.) 2
119 949-429 BOLT WASHER M4 (10 PCS.) 2
120 322-920 HOOK 1
121 326-708 HANDLE 1
122 323-208
MACHINE SCREW (W/WASHERS) M6X20 (BLACK) 2
* 123 326-701 GEAR CASE 1
INCLUD. 110 FOR USA, CAN, AUS, NZL, CHA
* 123 326-702 GEAR CASE 1 INCLUD. 110 FOR EUROPE
* 124 323-987 LEVER SPRING 1 FOR EUROPE
* 125 323-990 LEVER SHAFT 1 FOR EUROPE
* 126 323-979 LOCK LEVER (C) 1 FOR EUROPE
* 127 323-982 LEVER HOLDER 1 FOR EUROPE

Hitachi C 10FCH2 Specifications

General

Input power	1520 W
Power source	AC
Blade bore	30 mm
Blade diameter	255 mm
Idle speed (max)	5000 RPM
Sound power level	95 dB
Bevel setting (left)	45 °
Miter setting (left)	52 °
Sound pressure level	108 dB
Cutting capacity 45° miter	40 x 102 mm

Weight and Dimensions

Depth	628 mm
Width	460 mm
Height	561 mm
Weight	12000 g
