10
English
Miter sawing range Left 0° – 45° Right 0° – 45°
Bevel sawing range Left 0° – 45° Right 0° – 45°
Compound sawing range Left (Bevel) 0° – 45°, Left and Right (Miter) 0° – 45°
Right (Bevel) 0° – 45°, Left (Miter) 0° – 31°, Right (Miter) 0° – 45°
Net weight 44lbs. (20kg)
Cord 2 Conductor type cable 6.5ft. (1.99m)
*When slide fence assembly is used.
When cutting the workpiece which has the dimension of “*1” there might be some possibility of the lower end of the circular saw to
touch with the workpiece, even if the motor head is located at the lower limit position. Pay attention when cutting the workpiece. For
further details, refer to “PRACTICAL APPLICATIONS” on page 15.
ACCESSORIES
WARNING: Accessories for this power tool are mentioned in this Instruction Manual.
The use of any other attachment or accessory can be dangerous and could cause injury or
mechanical damage.
STANDARD ACCESSORIES
Fig. 3
OPTIONAL ACCESSORIES...sold separately
q Extension Holder and Stopper (Fig. 1) (Code No. 998866)
w Saw blade 10" (255mm) TCT Saw blade (Total teeth: 72) (Code No. 725206)
e Vise (A) Assembly (Code No. 308394)
NOTE: Accessories are subject to change without any obligation on the part of the HITACHI.
APPLICATIONS
Wood and aluminum sash.
e Slide Fence Assembly
For how to use, refer to
page 16.
t 10mm BOX
wrench (1 piece)
q 10" (255mm) TCT Saw
blade (1 piece)
w Dust bag (1 piece)
For how to use, refer to
page 23.
r Vise Assembly w/knob
bolt (1 piece)
For how to use, refer to page
16.
(No. of teeth 40 Code No.
310878A)
