Hitachi C 10FSH Instruction Manual

9
English
SPECIFICATIONS
Item Model C 10FSH / C 10FSB
Motor Type Series commutator motor
Power source Single-phase AC 60Hz
Voltage (Volts) 127
Full-load current (Amp) 11.4
Laser Marker Maximum output <1mW CLASS II Laser Product
(Only Model Wave length 400~700 nm
C10FSH) Laser medium Laser Diode
Applicable Outside Dia. 10" (255mm)
saw blade Hole Dia. 5/8" (15.9mm)
No load speed 3800/min
Max. Head Turntable Max. sawing dimension
sawing Miter 0 0 Max. Height 3-11/32" (85mm)
dimension
Max. Width 12-9/32" (312mm)
or
* Max. Height 3-9/16" (90mm)
Max. Width 11" (280mm)
With aux. board 19/32" (15mm)
0 Left 45° Max. Height 3-11/32" (85mm)
or Max. Width 8-19/32" (218mm)
Right 45° or
* Max. Height 3-9/16" (90mm)
Max. Width 7-1/2" (190mm)
With aux. board 19/32" (15mm)
0 Right 57° Max. Height 3-11/32" (85mm)
Max. Width 6-1/2" (165mm)
or
* Max. Height 3-9/16" (90mm)
Max. Width 5-25/32" (147mm)
With aux. board 13/32" (10mm)
Bevel Left 45° 0 Max. Height 2-3/16" (55mm)
Max. Width 12" (305mm)
or
* Max. Height 2-3/8" (60mm)
Max. Width 11" (280mm)
With aux. board 19/32" (15mm)
Right 45° 0 Max. Height 1-3/16" (30mm)
Max. Width 12" (305mm)
or
* Max. Height 1-3/8" (35mm)
Max. Width 11" (280mm)
With aux. board 19/32" (15mm)
Compound Left 45° Left 45° Max. Height 2-3/16" (55mm)
or Max. Width 8-19/32" (218mm)
Right 45° or
* Max. Height 2-3/8" (60mm)
Max. Width 7-1/2" (190mm)
With aux. board 19/32" (15mm)
Right 45° Left 31° Max. Height 1-3/16" (30mm)
Max. Width 10-7/32" (260mm)
or
* Max. Height 1-3/8" (35mm)
Max. Width 9-19/32" (230mm)
With aux. board 19/32" (15mm)
Right 45° Right 45° Max. Height 1-3/16" (30mm)
Max. Width 8-19/32" (218mm)
or
* Max. Height 1-3/8" (35mm)
Max. Width 7-1/2" (190mm)
With aux. board 19/32" (15mm)
Miter sawing range Left 0° – 45° Right 0° – 57°
Bevel sawing range Left 0° – 45° Right 0° – 45°
Compound sawing range Left (Bevel) 0° – 45°, Left and Right (Miter) 0° – 45°
Right (Bevel) 0° – 45°, Left (Miter) 0° – 31°, Right (Miter) 0° – 45°
Net weight 43lbs. (19.5kg)
Cord 2 Conductor type cable 6ft. (1.8m)
