APPLICATIONS
Wood (hard or soft woods)
UNPACKING
The parts illustrated in Fig. 4 described are packaged together with the tool. When unpacking, carefully
confirm that all parts are accounted for.
Fig. 4
1. Miter Gauge (1 piece) 8. Grip (1 piece)
2. Saw Blade Guard and Spreader Assembly (1 piece) 9. 6 × 90 mm Bolt (1 piece)
3. Elbow (1 piece) 10. 6 × 110 mm Bolt (1 piece)
4. Rip Fence (1 piece) 11. 6 mm Spring Washer (2 pieces)
5. Hex. Wrench (1 piece) 12. 6 mm Flat Washer (2 pieces)
6. Wrench (1 piece) 13. 8 × 20 mm Bolt (with / washers) (4 pieces)
7. Handle Bar (1 piece) 14. Set Plate (4 pieces)
15. Cusion (1 piece)
12
3
4
56
7
8
13 10 9
12 11
15
14
