3. Transportation and Handling
3.1 Transportation
Transporttheproductasclosetotheinstallation
locationaspracticablebeforeunpacking.
3.3 CombinationofCH-BoxandIndoorUnit
Combinationisasfollows.
Table3.1CombinationofIndoorUnit
3.2 HandlingofCH-Box
Do not put any foreign material into the indoor
unit and check to ensure that none exists in
the CH-Box before the installation and test run.
Otherwise, a re or failure, or something similar
may occur.
Do not put any material on the product.
Be careful not to damage insulation materials
of unit’s surface when lifting.
NOTES:
1. Exceedingthetotalcapacitymaycauseinsufcientperformanceandabnormalsound.Besureto
connecttheCH-Boxwithintheallowabletotalcapacity.
2. Incaseof8HPor10HPtypeindoorunitconnection:
Onlysingleunitperbranchisallowedtobeconnected.
Uptotwo8HPor10HPtypeindoorunitscanbeconnectedtotheCH-Boxwithinthe“MaximumTotal
CapacityofAllConnectedIndoorUnits”showninabovetable.
Makesuretoincreasethepipeconnectionsizebyusingtheappropriateaccessorypipe.
Model
CH-AP04MSSX
JCH-AP04MSSX
CH-AP08MSSX
JCH-AP08MSSX
CH-AP12MSSX
JCH-AP12MSSX
CH-AP16MSSX
JCH-AP16MSSX
NumberofBranches(forIndoorUnit) 4 8 12 16
SingleUnit
PerBranch
MaximumTotalCapacityof
AllConnectedIndoorUnits
16.0HPorless
(Max.44.8kW)
30.0HPorless
(Max.85.0kW)
30.0HPorless
(Max.85.0kW)
30.0HPorless
(Max.85.0kW)
MaximumTotalCapacityof
ConnectedIndoorUnitsPer
Branch
6.0HPorless
(Max.16.0kW)
6.0HPorless
(Max.16.0kW)
6.0HPorless
(Max.16.0kW)
6.0HPorless
(Max.16.0kW)
MultipleUnits
PerBranch
(*1)
MaximumNumberof
ConnectedIndoorUnitsPer
Branch
6 6 6 6
MaximumTotalCapacityof
AllConnectedIndoorUnits
16.0HPorless
(Max.44.8kW)
30.0HPorless
(Max.85.0kW)
30.0HPorless
(Max.85.0kW)
30.0HPorless
(Max.85.0kW)
MaximumTotalCapacityof
ConnectedIndoorUnitsPer
Branch
6.0HPorless
(Max.16.0kW)
6.0HPorless
(Max.16.0kW)
6.0HPorless
(Max.16.0kW)
6.0HPorless
(Max.16.0kW)
(*1) WhenmultipleindoorunitsareconnectedtothesamebranchofCH-Box,theyarecontrolledwiththe
sameoperationmode.
