Hitachi CH-Box - 4 Box Installation; Factory-Supplied Accessories

P5417025-rev.1
7
4. CH-Box Installation
● Do not install the CH-Box in a ammable
environment to avoid re or an explosion.
4.1 Factory-SuppliedAccessories
Checktoensurethatthefollowingaccessoriesare
packedwiththeCH-Box.
Table4.1Factory-SuppliedAccessories
NOTE
● Check to ensure that the ceiling slab is strong
enough.
● Do not install the CH-Box outdoors.
If installed outdoors, an electric hazard or
electric leakage may occur.
● Installation WARNING: Ensure that all safety
features, disconnects and interlocks are
in place and functioning properly prior to
putting the equipment into operation. Never
by-pass or jump-out any safety device or
switch.
Ifanyoftheseaccessoriesarenotpackedwiththe
unit,pleasecontactyourdistributor.
Unit:mm(inch)
No. Accessory
CH-AP04MSSX
JCH-AP04MSSX
Q’ty
CH-AP08MSSX
JCH-AP08MSSX
Q’ty
CH-AP12MSSX
JCH-AP12MSSX
Q’ty
CH-AP16MSSX
JCH-AP16MSSX
Q’ty
(1)
Accessory
Pipe
ID
f
12.7(1/2)
Flaring
f
15.88(5/8)
4 8 12 16
(2)
ID
f
6.35(1/4)
Flaring
f
9.52(3/8)
4 8 12 16
(3)
ID
f
19.05(3/4)
Flaring
f
15.88(5/8)
Flare Nut
2
Flare Nut
2
Flare Nut
2
Flare Nut
2
(4)
ID
f
22.2(7/8)
Flaring
f
15.88(5/8)
Flare Nut
1
Flare Nut
2
Flare Nut
2
Flare Nut
2
(5)
Insulation
Material
ID
f
26
(1)
4 8 12 16
(6)
ID
f
35
(1-3/8)
4 8 12 16
(7) Clamp
17 34 51 68
